MEAN WELL RSDW DC/DC Converter, 21.6V dc, 26.4 V dc/ 1.667 A, 160V dc Input, 40V dc Input 40 W, Through Hole, 85 °C Max
- RS Stock No.:
- 145-179
- Distrelec Article No.:
- 302-30-084
- Mfr. Part No.:
- RSDW40H-24
- Brand:
- MEAN WELL
Subtotal (1 unit)*
£52.20
(exc. VAT)
£62.64
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 27 April 2027
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £52.20 |
*price indicative
- RS Stock No.:
- 145-179
- Distrelec Article No.:
- 302-30-084
- Mfr. Part No.:
- RSDW40H-24
- Brand:
- MEAN WELL
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | MEAN WELL | |
| Product Type | DC/DC Converter | |
| Output Voltage 1 | 21.6V dc, 26.4V dc | |
| Minimum Input Voltage | 40V dc | |
| Maximum Input Voltage | 160V dc | |
| Output Current 1 | 1.667A | |
| Mount Type | Through Hole | |
| Maximum Output Power | 40W | |
| Standards/Approvals | No | |
| Series | RSDW | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 85°C | |
| Select all | ||
|---|---|---|
Brand MEAN WELL | ||
Product Type DC/DC Converter | ||
Output Voltage 1 21.6V dc, 26.4V dc | ||
Minimum Input Voltage 40V dc | ||
Maximum Input Voltage 160V dc | ||
Output Current 1 1.667A | ||
Mount Type Through Hole | ||
Maximum Output Power 40W | ||
Standards/Approvals No | ||
Series RSDW | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 85°C | ||
RoHS Status: Exempt
- COO (Country of Origin):
- TW
The MEANWELL DC-DC Railway Converter is a high-quality power supply unit suitable for various industrial applications. It features international standard pins, wide working temperature range and compliance with railway standard.
No minimum load required
Full encapsulated
Short circuit, overload, overvoltage protection
