Norcomp 178 15 Way Right Angle Through Hole D-sub Connector Plug, 2.77mm Pitch, with 4-40 Inserts/Board Lock

RS Stock No.:: 174-8688
Mfr. Part No.:: 178-015-613R491
Brand:: Norcomp

Norcomp 178 15 Way Right Angle Through Hole D-sub Connector Plug, 2.77mm Pitch, with 4-40 Inserts/Board Lock

6 In stock - FREE next working day delivery available

Added

Price Each

£11.86

(exc. VAT)

£14.23

(inc. VAT)

Units	Per unit
1 - 4	£11.86
5 - 24	£10.95
25 - 49	£10.13
50 - 99	£9.43
100 +	£8.85

RS Stock No.:: 174-8688
Mfr. Part No.:: 178-015-613R491
Brand:: Norcomp

Technical Reference

Legislation and Compliance

COO (Country of Origin):: TW

Product Details

Dual port d-subs available in 4 industry sizes/positions:
Standard Density (9 pin, 15 pin, 25 pin, 37 pin) & High Density (15 pin)
Low cost, high performance stamped contacts.
Stacked d-sub provides proper mating while maximizing board space.
Nickel plated shells have ground indents to provide better grounding & retention.
Metal shell for improved shielding.
Fully intermateable with other d-sub connectors.
Shell: Steel, nickel plating
Insulator: Glass-filled thermoplastic, (260°C process temp)
Stamped contacts: Brass | Plating: Gold flash

Specifications

Attribute	Value
Number of Contacts	15
Gender	Male
Body Orientation	Right Angle
Mounting Type	Through Hole
Pitch	2.77mm
D Connector Type	Dual Ports D-Sub
Mounting Hardware	4-40 Inserts/Board Lock
Termination Method	Solder
Current Rating	5.0A
Housing Material	Steel
Voltage Rating	1.0 kV
Length	38.99mm
Width	25.4mm
Depth	31.75mm
Contact Material	Brass
Dimensions	38.99 x 25.4 x 31.75mm
Series	178
Contact Plating	Gold Flash
Maximum Operating Temperature	+105°C
Minimum Operating Temperature	-55.0°C
Series Number	178
