Norcomp 170 25 Way Cable Mount D-sub Connector Socket, 2.77mm Pitch
- RS Stock No.:
- 174-8441
- Mfr. Part No.:
- 170-025-273L000
- Brand:
- Norcomp
Bulk discount available
Subtotal (1 tray of 50 units)*
£37.95
(exc. VAT)
£45.55
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 30 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tray* |
---|---|---|
50 - 50 | £0.759 | £37.95 |
100 - 200 | £0.726 | £36.30 |
250 + | £0.659 | £32.95 |
*price indicative
- RS Stock No.:
- 174-8441
- Mfr. Part No.:
- 170-025-273L000
- Brand:
- Norcomp
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Norcomp | |
Number of Contacts | 25 | |
Gender | Female | |
Body Orientation | Straight | |
Mounting Type | Cable Mount | |
Pitch | 2.77mm | |
Termination Method | Crimp | |
Current Rating | 5.0A | |
Housing Material | Steel | |
Voltage Rating | 500.0 V | |
Length | 53.04mm | |
Width | 12.6mm | |
Depth | 11.1mm | |
Series | 170 | |
Dimensions | 53.04 x 12.6 x 11.1mm | |
Minimum Operating Temperature | -50.0°C | |
Maximum Operating Temperature | +125°C | |
Series Number | 170 | |
Select all | ||
---|---|---|
Brand Norcomp | ||
Number of Contacts 25 | ||
Gender Female | ||
Body Orientation Straight | ||
Mounting Type Cable Mount | ||
Pitch 2.77mm | ||
Termination Method Crimp | ||
Current Rating 5.0A | ||
Housing Material Steel | ||
Voltage Rating 500.0 V | ||
Length 53.04mm | ||
Width 12.6mm | ||
Depth 11.1mm | ||
Series 170 | ||
Dimensions 53.04 x 12.6 x 11.1mm | ||
Minimum Operating Temperature -50.0°C | ||
Maximum Operating Temperature +125°C | ||
Series Number 170 | ||
- COO (Country of Origin):
- TW
Crimp & poke d-subs available in 5 industry sizes/positions
Standard Density (9 pin, 15 pin, 25 pin, 37 pin, 50 pin).
Low cost commercial version of military standard. Nickel or Tin shells.
Allows for easy loading of only the positions required.
Crimp & Snap-in contacts (sold separately).
Nylon insulator has a minimum contact retention of 10 lbs.
Contact current rating: 5 amps.
Shell: Steel, Tin or Nickel Plated
Insulator: Glass-filled thermoplastic (230°C process temp)
Standard Density (9 pin, 15 pin, 25 pin, 37 pin, 50 pin).
Low cost commercial version of military standard. Nickel or Tin shells.
Allows for easy loading of only the positions required.
Crimp & Snap-in contacts (sold separately).
Nylon insulator has a minimum contact retention of 10 lbs.
Contact current rating: 5 amps.
Shell: Steel, Tin or Nickel Plated
Insulator: Glass-filled thermoplastic (230°C process temp)
