Amphenol Communications Solutions FCE17 9 Way Right Angle Through Hole D-sub Connector Socket, 2.74mm Pitch, with 4-40

These Amphenol Filtered D-Sub FCE17 Series Right Angle Pin or Socket connectors are PCB mounted.

Filter Capacitance of 470 pF and 820 pF are available indicated by a 1or 4 in the Manufacturers Part Number i.e. FCE17-*****-*X** respectively
#4-40 UNC threaded Jack Screw holes
PCB Footprint B (10.29 mm)
Boardlocks are Tin plated Copper alloy
Insulation Resistance 3000 MΩ
Contact Resistance 15 mΩ

UL94V-0

Amphenol Filtered 'D' Connectors

These filtered connectors are compact interconnect devices that can filter unwanted EMI. The capacitors are mounted inside the connector between each of the contacts and the connector ground shell. They provide:

Better EMI Control – With minimized lead inductances and short, direct paths to ground of the filter, performance will typically out perform the same filter components on a P.C.B. by a factor of three to one
PCB Space Savings – Incorporating filter elements into the connector, enables simplification of the required filter schematic for the necessary performance plus a savings of 2-4 square inches
Cost Savings – Filter elements, such as inductors and capacitors, must no longer be purchased, stocked, assembled or tested. Fewer components means greater reliability at lower cost
Easy EMI/RFI Upgrade – These compact filtered connectors fit standard non-filtered connector footprints. For improved EMC performance, simply replace the existing connector with a filtered connector
EMC Compliance & Immunity – EMI that is generated from the electronic device, radiated or conducted, will be re-directed to chassis ground through the connector shell. This same device will also protect the system from external EMI/RFI noise (such as radio transmitters, ESD, or natural phenomena such as lightning) in the same way
