HARTING D-Sub 9 Way Through Hole D-sub Connector Plug, 2.74mm Pitch, with 4-40 UNC Nut
- RS Stock No.:
- 139-3661
- Mfr. Part No.:
- 09651617713
- Brand:
- HARTING
Bulk discount available
Subtotal (1 pack of 100 units)*
£287.70
(exc. VAT)
£345.20
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 16 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 100 - 100 | £2.877 | £287.70 |
| 200 + | £2.445 | £244.50 |
*price indicative
- RS Stock No.:
- 139-3661
- Mfr. Part No.:
- 09651617713
- Brand:
- HARTING
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | HARTING | |
| Number of Contacts | 9 | |
| Gender | Male | |
| Body Orientation | Straight | |
| Mounting Type | Through Hole | |
| Pitch | 2.74 mm, 2.84mm | |
| D Connector Type | Standard D-Sub | |
| Termination Method | Solder | |
| Mounting Hardware | 4-40 UNC Nut | |
| Current Rating | 6.5A | |
| Mixed Contact Layout | 9W2 | |
| Housing Material | Glass Fibre Reinforced Thermoplastic | |
| Length | 31.2mm | |
| Width | 12.5mm | |
| Depth | 6.2mm | |
| Dimensions | 31.2 x 12.5 x 6.2mm | |
| Contact Material | Copper Alloy | |
| Series | D-Sub | |
| Maximum Operating Temperature | +125°C | |
| Minimum Operating Temperature | -55.0°C | |
Select all | ||
|---|---|---|
Brand HARTING | ||
Number of Contacts 9 | ||
Gender Male | ||
Body Orientation Straight | ||
Mounting Type Through Hole | ||
Pitch 2.74 mm, 2.84mm | ||
D Connector Type Standard D-Sub | ||
Termination Method Solder | ||
Mounting Hardware 4-40 UNC Nut | ||
Current Rating 6.5A | ||
Mixed Contact Layout 9W2 | ||
Housing Material Glass Fibre Reinforced Thermoplastic | ||
Length 31.2mm | ||
Width 12.5mm | ||
Depth 6.2mm | ||
Dimensions 31.2 x 12.5 x 6.2mm | ||
Contact Material Copper Alloy | ||
Series D-Sub | ||
Maximum Operating Temperature +125°C | ||
Minimum Operating Temperature -55.0°C | ||
- COO (Country of Origin):
- CH
Harting 9 way Solder D-Sub Miniature Plugs Straight and Angled - 2.74 mm Pitch
From Harting, a range of 9 way solder D-sub miniature connectors with straight stamped male contacts. The DIN 41652 plugs have copper alloy contacts housed in a robust metal shell with dimples. Secured in the panel with a fixing flange and 4 to 40 UNC thread. The D-sub miniature connectors in this series have performance level 2 and 3.
Features and Benefits
• Robust metal shell
• 6.5A rated current
• Wave soldering termination
• Performance level 2 and 3
• Stamped contacts
• 6.5A rated current
• Wave soldering termination
• Performance level 2 and 3
• Stamped contacts
D-Sub Connectors - Harting
