Chauvin Arnoux MN38 Current Clamp, AC Adapter, 200A ac AC Max
- RS Stock No.:
- 227-4892
- Mfr. Part No.:
- P01120416
- Brand:
- Chauvin Arnoux
Subtotal (1 unit)*
£180.95
(exc. VAT)
£217.14
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 24 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 + | £180.95 |
*price indicative
- RS Stock No.:
- 227-4892
- Mfr. Part No.:
- P01120416
- Brand:
- Chauvin Arnoux
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Chauvin Arnoux | |
Adapter Type | AC | |
Maximum AC Current | 200A ac | |
Best Accuracy | 3 (0.5 → 10 A range) % | |
Resolution | 10 mA | |
Maximum Conductor Size | 20mm | |
Model Number p | MN38 | |
Select all | ||
---|---|---|
Brand Chauvin Arnoux | ||
Adapter Type AC | ||
Maximum AC Current 200A ac | ||
Best Accuracy 3 (0.5 → 10 A range) % | ||
Resolution 10 mA | ||
Maximum Conductor Size 20mm | ||
Model Number p MN38 | ||
- COO (Country of Origin):
- FR
The Chauvin Arnoux MN series ergonomic mini-clamps are designed to make light work of measuring low and medium currents from 0.01 A to 240 A AC. The shape of the jaws makes hooking onto cables easy, even in areas of restrictive access. The jaws can grip conductors up to 20 mm in diameter. Depending on the particular model, they have one or two calibres. The output is via either jack sockets or a lead with 4 mm Ø plugs, hence these clamps are compatible with all multimeters and testers on the market.
Designed with particular applications in mind such as measurement on current transformer outputs, on oscilloscopes and even of leakage currents.
