Molex Male Mini-Fit Jr. to Male Mini-Fit Jr. Crimped Wire, 75mm, 1.5mm², Red
- RS Stock No.:
- 205-7638
- Mfr. Part No.:
- 215342-2221
- Brand:
- Molex
Available to back order for despatch 31/12/2024
Price Each (In a Pack of 5)
£1.118
(exc. VAT)
£1.342
(inc. VAT)
Units | Per unit | Per Pack* |
|---|---|---|
| 5 - 20 | £1.118 | £5.59 |
| 25 - 45 | £0.914 | £4.57 |
| 50 + | £0.878 | £4.39 |
*price indicative
- RS Stock No.:
- 205-7638
- Mfr. Part No.:
- 215342-2221
- Brand:
- Molex
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- IN
Product Details
The Molex's mini-fit pre-crimped lead consist of fully tested UL listed cable which are crimped on both ends with gold plated male to pigtail crimp terminal. These crimp lead is ideal for use in wire to wire application or can be cut in half for use in wire to board application. Its colour is black and available with 75 mm long cable length which has 16 AWG wire size.
Fully tested cable decrease time to market
Conductor material brass
Multiple point of contact for redundancy and higher current carrying capacity
Conductor material brass
Multiple point of contact for redundancy and higher current carrying capacity
Specifications
Attribute | Value |
|---|---|
| Series | Mini-Fit Jr. |
| Crimp Terminal 1 | Mini-Fit Jr. |
| Crimp Terminal 2 | Mini-Fit Jr. |
| Crimp Terminal 1 Gender | Male |
| Crimp Terminal 2 Gender | Male |
| Wire Size | 1.5mm² |
| Cable Length | 75mm |
| Contact Plating | Gold |
| Sheath Colour | Red |
| Series Number | 215342 |
| Current Rating | 9 A |
| Wire Style | UL1015 |
