Igus chainflex CF5 Control Cable, 5 Cores, 0.75 mm², Unscreened, 50m, Green PVC Sheath, 18 AWG
- RS Stock No.:
- 210-0426
- Mfr. Part No.:
- CF5.07.05 (50m)
- Brand:
- Igus
Subtotal (1 reel of 50 metres)*
£174.40
(exc. VAT)
£209.30
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- Plus 100 unit(s) shipping from 06 October 2025
- Plus 999,999,850 unit(s) shipping from 27 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
---|---|---|
50 + | £3.488 | £174.40 |
*price indicative
- RS Stock No.:
- 210-0426
- Mfr. Part No.:
- CF5.07.05 (50m)
- Brand:
- Igus
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Igus | |
Series | chainflex CF5 | |
Number of Cores | 5 | |
Cross Sectional Area | 0.75 mm² | |
American Wire Gauge | 18 AWG | |
Conductor Material | Copper | |
Sheath Material | PVC | |
Sheath Colour | Green | |
Armoured | No | |
Screened/Unscreened | Unscreened | |
Screen Type | Unscreened | |
Outer Diameter | 7.5mm | |
Minimum Bend Radius | 4 x D | |
Length | 50m | |
Voltage Rating | 300/500 V | |
Current Rating | 12 A | |
Fire Behaviour | Flame Retardant | |
Maximum Operating Temperature | +70°C | |
Earth Cable | Yes | |
Conductor Resistance | 26 Ω/km | |
Cable Shape | Multicore | |
Minimum Operating Temperature | -15°C | |
Oil Resistant | Yes | |
Insulation Material | PVC | |
Select all | ||
---|---|---|
Brand Igus | ||
Series chainflex CF5 | ||
Number of Cores 5 | ||
Cross Sectional Area 0.75 mm² | ||
American Wire Gauge 18 AWG | ||
Conductor Material Copper | ||
Sheath Material PVC | ||
Sheath Colour Green | ||
Armoured No | ||
Screened/Unscreened Unscreened | ||
Screen Type Unscreened | ||
Outer Diameter 7.5mm | ||
Minimum Bend Radius 4 x D | ||
Length 50m | ||
Voltage Rating 300/500 V | ||
Current Rating 12 A | ||
Fire Behaviour Flame Retardant | ||
Maximum Operating Temperature +70°C | ||
Earth Cable Yes | ||
Conductor Resistance 26 Ω/km | ||
Cable Shape Multicore | ||
Minimum Operating Temperature -15°C | ||
Oil Resistant Yes | ||
Insulation Material PVC | ||
- COO (Country of Origin):
- DE
The Igus chainflex cables from igus are designed with one message in mind, cost down, life up. With our TPE jacket material, we provide products that can cope with highly demanding applications adopting very high abrasion resistance whilst providing excellent protection levels when faced with harsh chemical and oil-based environments. Our patented bundle design ensures small bend radius figures which make chainflex cables ideal for use in echain (cable carrier), flexible and fixed applications.
Small bend radii, ideal for space saving installation
Patented core bundled design to ensure long lasting lifetime in dynamic applications
Oil resistant Class 4 which supports almost unlimited oil + bio-oil resistance
Low angled braided screen optimised for use in continuous flexing applications
300/500v rated for use in control cable applications
Wide temperature ranges from -55°c to +100°c depending on application type
Guaranteed service life for use in echains, minimise risk of unplanned downtime
Long travel rated for reliable use up to 400m in echains®
Patented core bundled design to ensure long lasting lifetime in dynamic applications
Oil resistant Class 4 which supports almost unlimited oil + bio-oil resistance
Low angled braided screen optimised for use in continuous flexing applications
300/500v rated for use in control cable applications
Wide temperature ranges from -55°c to +100°c depending on application type
Guaranteed service life for use in echains, minimise risk of unplanned downtime
Long travel rated for reliable use up to 400m in echains®
Unscreened control cables are used in a wide variety of applications where EMC/EMI/Cross talk is not an issue. Core sizing ranges from 0.25mm²-2.5mm², with core identification using DIN 47100 colour coding or with black cores, white numerals + earth (GY) depending on the size of core required. CF5 is designed for heavy duty applications where the influence of oils is relatively light. Preferably for use on indoor applications or for outdoor applications at above freezing temperatures. Typical application areas include
storage and retrieval units, high-bay warehousing, machining units, packaging machines, quick handling, indoor cranes.
Medium UV resistance.
Oil-resistant (following DIN EN 50363-4-1).
Flame Retardant according to IEC 60332-1-2, CEI 20-35, FT1, VW1.
Silicone-free following PV 3.10.7 – status 1992.
UL/CSA style 11113 and 2570.
NFPA following NFPA 79-2018, chapter 12.9.
ROHS-II (Lead-free) following 2011/65/EC.
Clean room according to ISO Class 2.
CE following 2014/35/EU.
Note
chainflex® guarantee, now verified by UL - all igus flexible cables are thoroughly tested in our 2,750m laboratory with reliable specialist equipment where we have over 600 tests running simultaneously, to confidently provide our 36-month guarantee.
Oil-resistant (following DIN EN 50363-4-1).
Flame Retardant according to IEC 60332-1-2, CEI 20-35, FT1, VW1.
Silicone-free following PV 3.10.7 – status 1992.
UL/CSA style 11113 and 2570.
NFPA following NFPA 79-2018, chapter 12.9.
ROHS-II (Lead-free) following 2011/65/EC.
Clean room according to ISO Class 2.
CE following 2014/35/EU.
Note
chainflex® guarantee, now verified by UL - all igus flexible cables are thoroughly tested in our 2,750m laboratory with reliable specialist equipment where we have over 600 tests running simultaneously, to confidently provide our 36-month guarantee.
