Belden Belden SY SY Control Cable, 2 Cores, 1.5 mm², Screened, 50m, Transparent PVC Sheath, 15 AWG
- RS Stock No.:
- 379-334
- Mfr. Part No.:
- SYSD02.0050
- Brand:
- Belden
Unavailable
RS will no longer stock this product.
Alternative
This product is not currently available. Here is our alternative recommendation.
1 Reel of 50 Metre(s)
£139.77
(exc. VAT)
£167.72
(inc. VAT)
- RS Stock No.:
- 379-334
- Mfr. Part No.:
- SYSD02.0050
- Brand:
- Belden
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Belden | |
| Series | Belden SY | |
| Number of Cores | 2 | |
| Cross Sectional Area | 1.5 mm² | |
| Screened/Unscreened | Screened | |
| Length | 50m | |
| Sheath Colour | Transparent | |
| American Wire Gauge | 15 AWG | |
| Outer Diameter | 9.58mm | |
| Sheath Material | Polyvinyl Chloride PVC | |
| Screen Type | Galvanised Steel | |
| Earth Cable | Yes | |
| Conductor Material | Copper | |
| Bedding Material | PVC | |
| Conductor Resistance | 13.3 Ω/km | |
| Maximum Operating Temperature | +70°C | |
| Current Rating | 16 A | |
| Minimum Bend Radius | 10 x D | |
| Core Strands | 30/0.25 mm | |
| Voltage Rating | 300/500 V | |
| Insulation Material | PVC | |
| Oil Resistant | No | |
| Minimum Operating Temperature | -5°C | |
| Select all | ||
|---|---|---|
Brand Belden | ||
Series Belden SY | ||
Number of Cores 2 | ||
Cross Sectional Area 1.5 mm² | ||
Screened/Unscreened Screened | ||
Length 50m | ||
Sheath Colour Transparent | ||
American Wire Gauge 15 AWG | ||
Outer Diameter 9.58mm | ||
Sheath Material Polyvinyl Chloride PVC | ||
Screen Type Galvanised Steel | ||
Earth Cable Yes | ||
Conductor Material Copper | ||
Bedding Material PVC | ||
Conductor Resistance 13.3 Ω/km | ||
Maximum Operating Temperature +70°C | ||
Current Rating 16 A | ||
Minimum Bend Radius 10 x D | ||
Core Strands 30/0.25 mm | ||
Voltage Rating 300/500 V | ||
Insulation Material PVC | ||
Oil Resistant No | ||
Minimum Operating Temperature -5°C | ||
- COO (Country of Origin):
- CN
Flexible Armoured SY Type Mains Cable
Flexible mains cable, commonly known as an ’SY’ type, which has three layers of protection, combining the characteristics of a flexible mains cable with that of a steel wire armoured type.
Features and Benefits
·Flexible
·Good resistance to chemicals
·Flexible
·Good resistance to chemicals
Applications
·Ideal for applications where power is required in arduous situations, on automated or robotic equipment and where equipment may be subjected to vibration or movement.
·Ideal for applications where power is required in arduous situations, on automated or robotic equipment and where equipment may be subjected to vibration or movement.
Manufactured to VDE 2050 standard
Core colours:
·2-core: Brown, Blue
·3-core: Blue, Brown, Green/Yellow
·4-core: Blue, Brown, Black, Green/Yellow
·5-core: Blue, Brown, Black, Grey, Green/Yellow
·6-core: Green/Yellow + 5 numbered
·7-core: Green/Yellow + 6 numbered
·12-core: Green/Yellow + 11 numbered
·18 core: Green/Yellow + 17 numbered
·25 core: Green/Yellow + 24 numbered
·2-core: Brown, Blue
·3-core: Blue, Brown, Green/Yellow
·4-core: Blue, Brown, Black, Green/Yellow
·5-core: Blue, Brown, Black, Grey, Green/Yellow
·6-core: Green/Yellow + 5 numbered
·7-core: Green/Yellow + 6 numbered
·12-core: Green/Yellow + 11 numbered
·18 core: Green/Yellow + 17 numbered
·25 core: Green/Yellow + 24 numbered
Type SY
Note
SY control cables are not suitable for fixed wiring applications requiring compliance with the requirements set out in BS7671.
