Schneider Electric TeSys D LC2D Contactor, 110 V ac Coil, 3-Pole, 32 A, 15 kW, 3NO, 690 V ac

Subtotal (1 unit)*

£333.65

(exc. VAT)

£400.38

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 8 unit(s) ready to ship
  • Plus 4 unit(s) ready to ship from another location
  • Plus 5 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 +£333.65

*price indicative

Better World

Our Better World range features products that make it easy for you to make a greener product choice you can trust. Click here to find out more.

RS Stock No.:
818-8495
Mfr. Part No.:
LC2D32F7
Brand:
Schneider Electric
Find similar products by selecting one or more attributes.
Select all

Brand

Schneider Electric

Coil Voltage

110 V ac

Number of Poles

3

Contact Voltage Rating

690 V ac

Contact Current Rating

32 A

Range

TeSys D

Power Rating

15 kW

Series

LC2D

Function

Reversing

Normal State Configuration

3NO

Number Of Auxiliary Contacts

2

Terminal Type

Screw

Width

77mm

Length

90mm

Depth

86mm

Better World Product

Yes

Better World Verification

Green Premium

Maximum Operating Temperature

+60°C

Minimum Operating Temperature

-40°C

Non Compliant

COO (Country of Origin):
FR

Schneider Electric LC2D32F7


TeSys Deca reversing contactor, 3 poles (3NO), for motor control applications up to 32A/690V AC-3 (15kW@400V). Rated 32A AC-3 15kW@400V, it includes a 110V 50/60Hz AC coil, 2NO+2NC aux contacts, a mechanical interlock. It provides 110V 50/60Hz AC coils, 2NO+2NC built-in auxiliary contacts (NC mirror certified), connection by screw clamp terminals. For operating rates until 3600 cycles/hour and environments until 60°C, it procures high reliability and durability. Compact (90mm width), DIN-rail mounting or screw fixing. With pre-wired reversing power connections, mechanical interlock (without electrical interlocking). Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine), Green Premium compliant (RoHS/REACh). Assembled with mechanical interlock and pre-wired reversing circuit. Clear separation between power and control circuits, easy front access to coil and auxiliary contacts connections. Equipped with a 110V AC coil that can be supplied at 50Hz or 60Hz. Provides 4 built-in auxiliary contacts 2NO + 2NC, NC contacts are mirror certified suitable to be included in the control of safety systems. High electrical durability, guaranteed for 2 million cycles at 32A AC-3 440V, for demanding motor switching applications. Robust design with high making and breaking capacities up to 20 In. Connection by screw clamp terminals.

• IP20 rating indicates that it can withstand tools and objects larger than 12mm in size
• Mechanical service life of 15 million operating cycles for long-term use
• Rated impulse withstand voltage rating of 6kV to handle sudden power spikes
• 7.5kW power rating for use in heavy-duty applications

Applications


• Industrial fans
• Hydro-electric power plants
• Low-pressure compressors

What's the operating temperature range of this contactor?


This contactor has a wide operating temperature range of -40°C to +70°C, so it's suitable for use in harsh industrial settings.
