RS PRO RS318ND01 Contactor, 110V ac Coil, 3-Pole, 18 A, 7.5 kW 24V, 3V, 400 V
- RS Stock No.:
- 277-8439
- Brand:
- RS PRO
Subtotal (1 unit)*
£72.47
(exc. VAT)
£86.96
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 18 unit(s) shipping from 20 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £72.47 |
*price indicative
- RS Stock No.:
- 277-8439
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Coil Voltage | 110V ac | |
| Product Type | Contactor | |
| Number of Poles | 3 | |
| Contact Voltage | 3, 400V | |
| Contact Current | 18A | |
| Series | RS318ND01 | |
| Power Rating | 7.5kW | |
| Function | Motor Control, Self Locking | |
| Terminal Type | Screw | |
| Minimum Operating Temperature | -40°C | |
| Contactor Application | Lighting, Heating, Motor | |
| Operational Current Ie | 32A | |
| Control Circuit Voltage Uc | 24V | |
| Maximum Operating Temperature | 60°C | |
| Depth | 85mm | |
| Standards/Approvals | RoHS, cULus, CE, IEC/EN 60947-4-1 | |
| Width | 47mm | |
| Select all | ||
|---|---|---|
Brand RS PRO | ||
Coil Voltage 110V ac | ||
Product Type Contactor | ||
Number of Poles 3 | ||
Contact Voltage 3, 400V | ||
Contact Current 18A | ||
Series RS318ND01 | ||
Power Rating 7.5kW | ||
Function Motor Control, Self Locking | ||
Terminal Type Screw | ||
Minimum Operating Temperature -40°C | ||
Contactor Application Lighting, Heating, Motor | ||
Operational Current Ie 32A | ||
Control Circuit Voltage Uc 24V | ||
Maximum Operating Temperature 60°C | ||
Depth 85mm | ||
Standards/Approvals RoHS, cULus, CE, IEC/EN 60947-4-1 | ||
Width 47mm | ||
- COO (Country of Origin):
- AT
RS PRO Contactor
These RS PRO contactors bring you the best build standard and high-quality essential components suitable for earthed-neutral systems. These devices will provide reliable switching and safety features designed to switch large amounts of power through their contacts.
Features and Benefits
Durable design, making them versatile and adaptable in various environments
Increased protection; reduce the chance of equipment damage and enhance system reliability
High switching capacity, RS PRO contactors can manage large electrical loads, ensuring consistent performance
Applications
This range of RS PRO Contactors are ideal for Industrial Applications:
Motors
Lighting Circuits
Heating
Electrical Loads
