Allen Bradley 100S-C Contactor, 24V dc Coil, 3-Pole, 43 A, 34 kW 24V dc, 3 NO, 690V ac
- RS Stock No.:
- 269-3101
- Mfr. Part No.:
- 100S-C43EJ22BC
- Brand:
- Allen Bradley
Subtotal (1 unit)*
£276.64
(exc. VAT)
£331.97
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit |
|---|---|
| 1 + | £276.64 |
*price indicative
- RS Stock No.:
- 269-3101
- Mfr. Part No.:
- 100S-C43EJ22BC
- Brand:
- Allen Bradley
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Allen Bradley | |
| Coil Voltage | 24V dc | |
| Product Type | Contactor | |
| Number of Poles | 3 | |
| Contact Voltage | 690V ac | |
| Contact Current | 43A | |
| Power Rating | 34kW | |
| Series | 100S-C | |
| Mount Type | DIN Rail | |
| Normal State Configuration | 3 NO | |
| Auxiliary Contact Configuration | 2 NO/2 NC | |
| Terminal Type | Screw | |
| Control Circuit Voltage Uc | 24V dc | |
| Contactor Application | Safety application | |
| Minimum Operating Temperature | -25°C | |
| Operational Current Ie | 43A | |
| Maximum Operating Temperature | 60°C | |
| Standards/Approvals | UKCA, DOC, Eurasion Economic Community China CCC, LVD Type Approval Korean KC, Morocco, SUVA, Australian RCM | |
| Length | 232mm | |
| Depth | 146mm | |
| Width | 54mm | |
| Pole and Throw Configuration | 3P | |
| Select all | ||
|---|---|---|
Brand Allen Bradley | ||
Coil Voltage 24V dc | ||
Product Type Contactor | ||
Number of Poles 3 | ||
Contact Voltage 690V ac | ||
Contact Current 43A | ||
Power Rating 34kW | ||
Series 100S-C | ||
Mount Type DIN Rail | ||
Normal State Configuration 3 NO | ||
Auxiliary Contact Configuration 2 NO/2 NC | ||
Terminal Type Screw | ||
Control Circuit Voltage Uc 24V dc | ||
Contactor Application Safety application | ||
Minimum Operating Temperature -25°C | ||
Operational Current Ie 43A | ||
Maximum Operating Temperature 60°C | ||
Standards/Approvals UKCA, DOC, Eurasion Economic Community China CCC, LVD Type Approval Korean KC, Morocco, SUVA, Australian RCM | ||
Length 232mm | ||
Depth 146mm | ||
Width 54mm | ||
Pole and Throw Configuration 3P | ||
RoHS Status: Exempt
- COO (Country of Origin):
- CH
The Rockwell Automation 100S series safety contactors provide mechanically linked positively guided contacts, which is required in feedback circuits for modern safety applications. The mechanically linked N.C auxiliary contacts do not change state when a power pole welds. In addition, these auxiliary contacts are ideally suited for low energy applications or feedback control circuits with multiple series connected N.C auxiliary contacts.
Front mounted auxiliary contacts
SUVA third party certification
Protective cover to prevent manual operation
Red contact housing for easy identification
Gold bifurcated auxiliary contacts
