ABB GJL131 Contactor, 17V dc, 32 V dc Coil, 3-Pole, 20 A, 5.5 kW 32V dc, 3 NO/1 NC, 690V
- RS Stock No.:
- 253-4840
- Mfr. Part No.:
- GJL1313061R5011
- Brand:
- ABB
Subtotal (1 unit)*
£93.13
(exc. VAT)
£111.76
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 2 unit(s) shipping from 20 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £93.13 |
*price indicative
- RS Stock No.:
- 253-4840
- Mfr. Part No.:
- GJL1313061R5011
- Brand:
- ABB
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | ABB | |
| Product Type | Contactor | |
| Coil Voltage | 17, 32V dc | |
| Number of Poles | 3 | |
| Contact Voltage | 690V | |
| Contact Current | 20A | |
| Series | GJL131 | |
| Power Rating | 5.5kW | |
| Mount Type | DIN Rail | |
| Function | Mini Contactor | |
| Normal State Configuration | 3 NO/1 NC | |
| Number of Auxiliary Contacts | 1 | |
| Terminal Type | Screw | |
| Contactor Application | Control Unit | |
| Control Circuit Voltage Uc | 32V dc | |
| Minimum Operating Temperature | -30°C | |
| Operational Current Ie | 20A | |
| Maximum Operating Temperature | 55°C | |
| Depth | 46.7mm | |
| Standards/Approvals | IEC/EN 60947-5-1, IEC/EN 60947-1, IEC/EN 60947-4-1 | |
| Length | 46.7mm | |
| Width | 47mm | |
| Pole and Throw Configuration | 3 | |
| Select all | ||
|---|---|---|
Brand ABB | ||
Product Type Contactor | ||
Coil Voltage 17, 32V dc | ||
Number of Poles 3 | ||
Contact Voltage 690V | ||
Contact Current 20A | ||
Series GJL131 | ||
Power Rating 5.5kW | ||
Mount Type DIN Rail | ||
Function Mini Contactor | ||
Normal State Configuration 3 NO/1 NC | ||
Number of Auxiliary Contacts 1 | ||
Terminal Type Screw | ||
Contactor Application Control Unit | ||
Control Circuit Voltage Uc 32V dc | ||
Minimum Operating Temperature -30°C | ||
Operational Current Ie 20A | ||
Maximum Operating Temperature 55°C | ||
Depth 46.7mm | ||
Standards/Approvals IEC/EN 60947-5-1, IEC/EN 60947-1, IEC/EN 60947-4-1 | ||
Length 46.7mm | ||
Width 47mm | ||
Pole and Throw Configuration 3 | ||
- COO (Country of Origin):
- DE
The ABB TBC7-30-01 mini contactor is a compact 3 pole contactor with 1 auxiliary contact and screw terminals. Its ideally suited for applications where reliability is a must and space is at a premium. Mini contactors are used in residential buildings, commercial buildings and industrial applications for the control of single or three-phase loads up to 5.5 kW (AC-3) and 20 A / 690 V (AC-1) or switching of control signals.
Degree of protection IP20
Ambient air temperature for operation is -30 to +70 °C
Mechanical durability 10000000 cycle
