ABB AF09ZB-30-10RT-21 AF Contactor, 60 V Coil, 3-Pole, 25 A, 4 kW, 3NO
- RS Stock No.:
- 225-5839
- Mfr. Part No.:
- 1SBL136060R2110 AF09ZB-30-10RT-21
- Brand:
- ABB
Subtotal (1 unit)*
£100.15
(exc. VAT)
£120.18
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 2 unit(s) ready to ship
- Plus 10 unit(s) shipping from 16 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £100.15 |
*price indicative
- RS Stock No.:
- 225-5839
- Mfr. Part No.:
- 1SBL136060R2110 AF09ZB-30-10RT-21
- Brand:
- ABB
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | ABB | |
| Coil Voltage | 60 V | |
| Number of Poles | 3 | |
| Contact Current Rating | 25 A | |
| Series | AF | |
| Power Rating | 4 kW | |
| Range | AF09ZB-30-10RT-21 | |
| Function | Motor Control | |
| Normal State Configuration | 3NO | |
| Width | 45mm | |
| Length | 77mm | |
| Depth | 77mm | |
Select all | ||
|---|---|---|
Brand ABB | ||
Coil Voltage 60 V | ||
Number of Poles 3 | ||
Contact Current Rating 25 A | ||
Series AF | ||
Power Rating 4 kW | ||
Range AF09ZB-30-10RT-21 | ||
Function Motor Control | ||
Normal State Configuration 3NO | ||
Width 45mm | ||
Length 77mm | ||
Depth 77mm | ||
ABB Series AF Contactor, 60V Coil Voltage, 25A Contact Current Rating - 1SBL136060R2110
This contactor is designed for motor control applications in industrial settings. It features three poles and operates with a coil voltage of 60V, managing contact current up to 25A. The compact design with ring-tongue terminals is suitable for DIN rail mounting, offering versatility in various installations. The device's dimensions are 77mm x 45mm x 77mm, making it ideal for space-constrained environments.
Features & Benefits
• Controls motors up to 4 kW at 400V AC
• Operates efficiently in a voltage range of 24-60V
• Built-in surge protection enhances durability
• Single built-in auxiliary contact streamlines wiring
• Maintains performance in extreme temperature conditions
• Simple installation with DIN rail mounting capability
• Operates efficiently in a voltage range of 24-60V
• Built-in surge protection enhances durability
• Single built-in auxiliary contact streamlines wiring
• Maintains performance in extreme temperature conditions
• Simple installation with DIN rail mounting capability
Applications
• Used for motor control in industrial machinery
• Suitable for power distribution systems requiring a 60V contactor
• Ideal for demanding high switching frequencies
• Utilised in environments requiring robust electrical contactors
• Applied in control circuits for automation equipment
• Suitable for power distribution systems requiring a 60V contactor
• Ideal for demanding high switching frequencies
• Utilised in environments requiring robust electrical contactors
• Applied in control circuits for automation equipment
What are the temperature limits for effective operation?
This device operates effectively within a temperature range of -40°C to +70°C when not fitted with a thermal overload relay, and -25°C to +60°C when equipped.
How does the built-in auxiliary contact benefit users?
The single auxiliary contact simplifies the control circuit design, allowing for efficient feedback and signalling without requiring additional components.
What makes this contactor suitable for unreliable power networks?
The wide control voltage range from 24V to 60V effectively accommodates voltage fluctuations, ensuring consistent performance even in unstable conditions.
How do ring-tongue terminals enhance installation?
Ring-tongue terminals provide a secure and reliable connection, which reduces the risk of loosening over time, thereby enhancing the overall safety of the installation.
