Schneider Electric TeSys F Contactor, 230 V Coil, 3-Pole, 1.5 kW 230 V, 3 NO
- RS Stock No.:
- 220-1284
- Mfr. Part No.:
- LC1K0601P72
- Brand:
- Schneider Electric
Image representative of range
Subtotal (1 unit)*
£33.90
(exc. VAT)
£40.68
(inc. VAT)
FREE delivery for orders over £50.00
- Plus 9 unit(s) shipping from 19 January 2026
Units | Per unit |
|---|---|
| 1 + | £33.90 |
*price indicative
Better World
Our Better World range features products that make it easy for you to make a greener product choice you can trust. Click here to find out more.
- RS Stock No.:
- 220-1284
- Mfr. Part No.:
- LC1K0601P72
- Brand:
- Schneider Electric
Select all | Attribute | Value |
|---|---|---|
| Brand | Schneider Electric | |
| Coil Voltage | 230 V | |
| Product Type | Contactor | |
| Number of Poles | 3 | |
| Series | TeSys F | |
| Power Rating | 1.5kW | |
| Function | Motor Control | |
| Mount Type | Plate | |
| Normal State Configuration | 3 NO | |
| Auxiliary Contact Configuration | 1 NC | |
| Number of Auxiliary Contacts | 1 | |
| Terminal Type | Screw Clamp | |
| Operational Current Ie | 6A | |
| Contactor Application | Motor Control | |
| Control Circuit Voltage Uc | 230 V | |
| Minimum Operating Temperature | -50°C | |
| Maximum Operating Temperature | 80°C | |
| Length | 58mm | |
| Standards/Approvals | IEC 60947-4-1 | |
| Depth | 57mm | |
| Width | 45 mm | |
| Better World Product | Yes | |
| Pole and Throw Configuration | 3 | |
| Select all | ||
|---|---|---|
Brand Schneider Electric | ||
Coil Voltage 230 V | ||
Product Type Contactor | ||
Number of Poles 3 | ||
Series TeSys F | ||
Power Rating 1.5kW | ||
Function Motor Control | ||
Mount Type Plate | ||
Normal State Configuration 3 NO | ||
Auxiliary Contact Configuration 1 NC | ||
Number of Auxiliary Contacts 1 | ||
Terminal Type Screw Clamp | ||
Operational Current Ie 6A | ||
Contactor Application Motor Control | ||
Control Circuit Voltage Uc 230 V | ||
Minimum Operating Temperature -50°C | ||
Maximum Operating Temperature 80°C | ||
Length 58mm | ||
Standards/Approvals IEC 60947-4-1 | ||
Depth 57mm | ||
Width 45 mm | ||
Better World Product Yes | ||
Pole and Throw Configuration 3 | ||
- COO (Country of Origin):
- FR
