Siemens SIRIUS 3RT Size S00, 3RT2 Contactor, 24 V dc Coil, 3-Pole, 7 A, 3 kW, 1NC, 400 V ac
- RS Stock No.:
- 203-2669
- Mfr. Part No.:
- 3RT2015-2FB42
- Brand:
- Siemens
Subtotal (1 unit)*
£40.37
(exc. VAT)
£48.44
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 6 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £40.37 |
*price indicative
Better World
Our Better World range features products that make it easy for you to make a greener product choice you can trust. Click here to find out more.
- RS Stock No.:
- 203-2669
- Mfr. Part No.:
- 3RT2015-2FB42
- Brand:
- Siemens
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Siemens | |
| Coil Voltage | 24 V dc | |
| Number of Poles | 3 | |
| Contact Voltage Rating | 400 V ac | |
| Contact Current Rating | 7 A | |
| Range | SIRIUS 3RT | |
| Series | Size S00, 3RT2 | |
| Power Rating | 3 kW | |
| Function | Reversing | |
| Normal State Configuration | 1NC | |
| Number Of Auxiliary Contacts | 1 | |
| Auxiliary Contact Configuration | 1NC | |
| Terminal Type | Spring-Loaded | |
| Length | 70mm | |
| Width | 45mm | |
| Depth | 73mm | |
| Better World Claim | Low carbon manufacture | |
| Better World Product | Yes | |
| Load Current | 7A | |
| Load Voltage | 400V ac | |
| Minimum Operating Temperature | -25°C | |
| Maximum Operating Temperature | +60°C | |
| Mounting Style | DIN Rail | |
| Control Voltage | 24 V dc | |
Select all | ||
|---|---|---|
Brand Siemens | ||
Coil Voltage 24 V dc | ||
Number of Poles 3 | ||
Contact Voltage Rating 400 V ac | ||
Contact Current Rating 7 A | ||
Range SIRIUS 3RT | ||
Series Size S00, 3RT2 | ||
Power Rating 3 kW | ||
Function Reversing | ||
Normal State Configuration 1NC | ||
Number Of Auxiliary Contacts 1 | ||
Auxiliary Contact Configuration 1NC | ||
Terminal Type Spring-Loaded | ||
Length 70mm | ||
Width 45mm | ||
Depth 73mm | ||
Better World Claim Low carbon manufacture | ||
Better World Product Yes | ||
Load Current 7A | ||
Load Voltage 400V ac | ||
Minimum Operating Temperature -25°C | ||
Maximum Operating Temperature +60°C | ||
Mounting Style DIN Rail | ||
Control Voltage 24 V dc | ||
- COO (Country of Origin):
- DE
Siemens size S00, 3RT2 Series Contactor, 3 Poles, 400V AC Contact Voltage Rating - 3RT2015-2FB42
This contactor is a vital component in automation systems, designed for effective control of electrical devices. Featuring a 3-pole configuration, it operates at a coil voltage of 24V DC and is suited for loads up to 7A at 400V AC. With dimensions of 70mm in length, 45mm in width, and 73mm in depth, it fits neatly onto standard DIN rails, facilitating straightforward installation in various operating environments.
Features & Benefits
• Integrates an auxiliary contact for enhanced functionality
• Spring-loaded terminals allow for quick, reliable connections
• Designed for reversing applications, improving versatility
• High mechanical service life of 30 million cycles ensures durability
• Spring-loaded terminals allow for quick, reliable connections
• Designed for reversing applications, improving versatility
• High mechanical service life of 30 million cycles ensures durability
Applications
• Used for controlling motors in industrial automation
• Suitable for electrical panels and machinery control
• Ideal for where space-saving is essential
• Used in systems requiring frequent switching operations
• Suitable for electrical panels and machinery control
• Ideal for where space-saving is essential
• Used in systems requiring frequent switching operations
What current ratings make this suitable for diverse applications?
It is rated for a maximum load current of 7A at 400V AC, making it proficient for various industrial tasks. The design can accommodate different operational currents according to specific needs, providing flexibility.
How do the dimensions impact installation on DIN rails?
With a compact design measuring 70mm by 45mm, it is engineered for easy mounting on standard 35mm DIN rails, ensuring efficient use of panel space.
What temperature conditions can this contactor withstand?
It can operate effectively from -25°C to +60°C, making it ideal for a range of environments, from cold storage facilities to high-temperature industrial sites.
