Eaton's DILE mini contactor overload relays reflect a long tradition of reliable, code compliant and efficient power distribution in any automation and control environments. These circuit breakers provide premium protection for overheating wires, overloads and short circuits in residential, commercial, industrial and hazardous areas and are ideally suited for use within harsh environments with high temperatures.

The DILE mini auxiliary contactor overload relays have compact dimensions and a modular design for the highest packing densities. Their space-saving size allows these mini contactor relays to be used wherever small motors or loads need to be controlled and switched. With an extended performance range of up to 5.5 kW at 400 V, an output range up to 7A and extensive approvals that mean they are suitable to be used worldwide.

The DILE mini contactor relays are available as AC versions (for control current networks from 24 V to 480 V with 50 Hz or 60 Hz) or DC versions (for control current versions from 12 V to 220 V). The DC operated versions have the suppressor as a diode-resistor combination integrated into the device.

Within the DILER series of contactor overload relays Eaton offers both a spring-loaded terminal and a screw terminal version with interlocked opposing contacts allowing the devices to be expanded to up to 8 auxiliary contacts.

• AC drive - for control voltages from 24 V to 600 V, at 50 Hz or 60 Hz
• DC drive - for control voltages from 12 V to 250 V
• UL and CSA approvals
• For controlling motors up to 5.5 kW
• DC-operated devices with integrated suppressor circuits
• Auxiliary NC with mirror contacts for use in safety-related applications
• Low power consumption - can be controlled directly from a PLC

This contactor relay is a crucial component for controlling electrical circuits in various automation systems. Designed for devices operating on 230 V AC, it delivers dependable performance in industrial settings. With a 4 pole configuration, this unit supports effective switching and enhances electrical control.

• Designed for AC operation with a coil voltage of 230V
• 4 poles enable efficient management of multiple circuits
• Maximum contact voltage rating of 400V enhances safety
• Durable screw terminal type ensures strong connections
• Suitable for DIN rail mounting for straightforward installation

• Ideal for controlling lighting systems in commercial spaces
• Employed for motor control in various electrical
• Effective in HVAC systems for fan and pump operations
• Suitable for automation solutions requiring high electrical reliability

The rated operational current is 3A at a maximum contact voltage of 400V AC.

Yes, it operates effectively within a temperature range of -25°C to +50°C.

It is compatible with DIN rail mounting, allowing for easy installation.

Eaton formerly known as Moeller
