Eaton Moeller DILER DILER Contactor Relay, 440 V Coil, 4-Pole, 6 A, 25 VA, 2NC, 2NO, 600 V ac
- RS Stock No.:
- 235-327
- Mfr. Part No.:
- 051778 DILER-22(380V50HZ,440V60HZ)
- Brand:
- Eaton
Subtotal (1 unit)*
£41.50
(exc. VAT)
£49.80
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 10 November 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £41.50 |
*price indicative
- RS Stock No.:
- 235-327
- Mfr. Part No.:
- 051778 DILER-22(380V50HZ,440V60HZ)
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Coil Voltage | 440 V | |
| Number of Poles | 4 | |
| Contact Voltage Rating | 600 V ac | |
| Contact Current Rating | 6 A | |
| Series | DILER | |
| Power Rating | 25 VA | |
| Range | Moeller DILER | |
| Normal State Configuration | 2NC, 2NO | |
Select all | ||
|---|---|---|
Brand Eaton | ||
Coil Voltage 440 V | ||
Number of Poles 4 | ||
Contact Voltage Rating 600 V ac | ||
Contact Current Rating 6 A | ||
Series DILER | ||
Power Rating 25 VA | ||
Range Moeller DILER | ||
Normal State Configuration 2NC, 2NO | ||
RoHS Status: Exempt
- COO (Country of Origin):
- DE
The Eaton DILER series contactor relay is engineered to optimise performance in demanding industrial environments. With its versatile operating voltages of 380V at 50Hz and 440V at 60Hz, this control relay accommodates a variety of applications. Its robust design features two normally open and two normally closed contacts, ensuring reliable operation under continuous load conditions. The incorporation of screw terminals guarantees secure connections, while compliance with multiple international standards ensures safety and reliability. Suitable for AC operations, the DILER series not only meets but exceeds expectations through its rigorous testing for mechanical lifespan and environmental resilience, making it an ideal choice for sophisticated control circuits.
Designed for seamless integration into control panels
Capable of withstanding up to 10 million mechanical operations
Engineered with interlocked opposing contacts for enhanced safety
Operates efficiently at a frequency of 9000 operations per hour
Features protection against direct contact and electrical shock
Allows flexible mounting options to suit various installation needs
Built to endure harsh climatic conditions with a wide temperature range
Certified for compliance with CE, UL, and CSA standards
Excels in electrical performance with a rated operational current of 6 A for AC-15 applications
Delivers exceptional reliability with low power consumption in sealing and pick-up modes
Capable of withstanding up to 10 million mechanical operations
Engineered with interlocked opposing contacts for enhanced safety
Operates efficiently at a frequency of 9000 operations per hour
Features protection against direct contact and electrical shock
Allows flexible mounting options to suit various installation needs
Built to endure harsh climatic conditions with a wide temperature range
Certified for compliance with CE, UL, and CSA standards
Excels in electrical performance with a rated operational current of 6 A for AC-15 applications
Delivers exceptional reliability with low power consumption in sealing and pick-up modes
