Schneider Electric, TeSyS CA Control Relay 2 NO/2 NC, 10A Contact Rating, 3 W, 110V dc
- RS Stock No.:
- 256-4086
- Mfr. Part No.:
- CA3KN22FD3
- Brand:
- Schneider Electric
Subtotal (1 unit)*
£80.11
(exc. VAT)
£96.13
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 3 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £80.11 |
*price indicative
Better World
Our Better World range features products that make it easy for you to make a greener product choice you can trust. Click here to find out more.
- RS Stock No.:
- 256-4086
- Mfr. Part No.:
- CA3KN22FD3
- Brand:
- Schneider Electric
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Schneider Electric | |
| Product Type | Control Relay | |
| Relay Contact Current | 10A | |
| Series | TeSyS CA | |
| Mount Type | Direct | |
| Power Rating | 3W | |
| Normal State Configuration | 2 NO/2 NC | |
| Terminal Type | Lug Ring Terminal | |
| Reset Method | Automatic & Manual | |
| IP Rating | IP2X | |
| Adjustable Current Range | 28 to 115 A | |
| Minimum Operating Temperature | -25°C | |
| Width | 58mm | |
| Contact Voltage | 250V | |
| Maximum Operating Temperature | 60°C | |
| Standards/Approvals | UL 60947-4-1, JIS C8201-5-1, JIS C8201-4-1, EN/IEC 60947-5-1, EN/IEC 60947-4-1, CSA C22.2 No 60947-4-1 | |
| Depth | 45mm | |
| Better World Product | Yes | |
| Control Voltage | 110V dc | |
| Select all | ||
|---|---|---|
Brand Schneider Electric | ||
Product Type Control Relay | ||
Relay Contact Current 10A | ||
Series TeSyS CA | ||
Mount Type Direct | ||
Power Rating 3W | ||
Normal State Configuration 2 NO/2 NC | ||
Terminal Type Lug Ring Terminal | ||
Reset Method Automatic & Manual | ||
IP Rating IP2X | ||
Adjustable Current Range 28 to 115 A | ||
Minimum Operating Temperature -25°C | ||
Width 58mm | ||
Contact Voltage 250V | ||
Maximum Operating Temperature 60°C | ||
Standards/Approvals UL 60947-4-1, JIS C8201-5-1, JIS C8201-4-1, EN/IEC 60947-5-1, EN/IEC 60947-4-1, CSA C22.2 No 60947-4-1 | ||
Depth 45mm | ||
Better World Product Yes | ||
Control Voltage 110V dc | ||
- COO (Country of Origin):
- FR
The Schneider Electric control relay provides up to 24V AC coil with integral suppression device available, connection by spring terminals. For high operating rates until 180 cycles per min and ambient temperature -25°C to +50°C, it procures high reliability and durability. It is compact and has DIN rail or fixing by screw.
Optimized size to save customer cabinet space
Wide range of accessories to satisfy different customer usage
Easier to install and operate with multi-standard screws
