WEG, CWCA0 Overload Relay 1 NO/3 NC, 10A Contact Rating, 24V ac 4P
- RS Stock No.:
- 122-1011
- Mfr. Part No.:
- CWCA0-13-00D02
- Brand:
- WEG
Subtotal (1 unit)*
£24.92
(exc. VAT)
£29.90
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 03 November 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £24.92 |
*price indicative
- RS Stock No.:
- 122-1011
- Mfr. Part No.:
- CWCA0-13-00D02
- Brand:
- WEG
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | WEG | |
| Product Type | Overload Relay | |
| Relay Contact Current | 10A | |
| Series | CWCA0 | |
| Pole and Throw Configuration | 4P | |
| Normal State Configuration | 1 NO/3 NC | |
| Terminal Type | Screw | |
| Width | 45mm | |
| Minimum Operating Temperature | -25°C | |
| Number of Auxiliary Contacts | 4 | |
| Contact Voltage | 690V ac | |
| Length | 58mm | |
| Maximum Operating Temperature | 55°C | |
| Depth | 52mm | |
| Control Voltage | 24V ac | |
| Select all | ||
|---|---|---|
Brand WEG | ||
Product Type Overload Relay | ||
Relay Contact Current 10A | ||
Series CWCA0 | ||
Pole and Throw Configuration 4P | ||
Normal State Configuration 1 NO/3 NC | ||
Terminal Type Screw | ||
Width 45mm | ||
Minimum Operating Temperature -25°C | ||
Number of Auxiliary Contacts 4 | ||
Contact Voltage 690V ac | ||
Length 58mm | ||
Maximum Operating Temperature 55°C | ||
Depth 52mm | ||
Control Voltage 24V ac | ||
RoHS Status: Exempt
- COO (Country of Origin):
- BR
CWC Series
Professional range of WEG contactors from the CWC Series designed for switching of electric motors. The contactors are modular and compact but at the same time robust and highly reliable. Built and tested according to IEC/EN60947 and DIN VDE 0660. Direct mounting capabilities. The controllers include contactors and reversing contactors.
AC/DC Operated
Screw Terminals
DIN Rail or Panel Mount
Compact space saving design
Built in auxiliary contacts
