WEG, CWC LINE Overload Relay 3 NO/1 NC, 10A Contact Rating, 24V ac 4
- RS Stock No.:
- 122-0810
- Mfr. Part No.:
- CWCA0-31-00D02
- Brand:
- WEG
Subtotal (1 unit)*
£24.92
(exc. VAT)
£29.90
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 22 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £24.92 |
*price indicative
- RS Stock No.:
- 122-0810
- Mfr. Part No.:
- CWCA0-31-00D02
- Brand:
- WEG
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | WEG | |
| Product Type | Overload Relay | |
| Relay Contact Current | 10A | |
| Series | CWC LINE | |
| Mount Type | DIN Rail | |
| Pole and Throw Configuration | 4 | |
| Normal State Configuration | 3 NO/1 NC | |
| Terminal Type | Screw | |
| IP Rating | IP20 | |
| Width | 45mm | |
| Number of Auxiliary Contacts | 4 | |
| Minimum Operating Temperature | -25°C | |
| Contact Voltage | 690V ac | |
| Maximum Operating Temperature | 55°C | |
| Length | 58mm | |
| Depth | 52mm | |
| Standards/Approvals | IEC 60034-30-1, IEC 60947-1, IEC 60947-2, IEC 60947-4-1 | |
| Supply Voltage | 100, 50V | |
| Control Voltage | 24V ac | |
| Select all | ||
|---|---|---|
Brand WEG | ||
Product Type Overload Relay | ||
Relay Contact Current 10A | ||
Series CWC LINE | ||
Mount Type DIN Rail | ||
Pole and Throw Configuration 4 | ||
Normal State Configuration 3 NO/1 NC | ||
Terminal Type Screw | ||
IP Rating IP20 | ||
Width 45mm | ||
Number of Auxiliary Contacts 4 | ||
Minimum Operating Temperature -25°C | ||
Contact Voltage 690V ac | ||
Maximum Operating Temperature 55°C | ||
Length 58mm | ||
Depth 52mm | ||
Standards/Approvals IEC 60034-30-1, IEC 60947-1, IEC 60947-2, IEC 60947-4-1 | ||
Supply Voltage 100, 50V | ||
Control Voltage 24V ac | ||
RoHS Status: Exempt
- COO (Country of Origin):
- BR
CWC Series
Professional range of WEG contactors from the CWC Series designed for switching of electric motors. The contactors are modular and compact but at the same time robust and highly reliable. Built and tested according to IEC/EN60947 and DIN VDE 0660. Direct mounting capabilities. The controllers include contactors and reversing contactors.
AC/DC Operated
Screw Terminals
DIN Rail or Panel Mount
Compact space saving design
Built in auxiliary contacts
