WEG, CWCA0 Overload Relay 2 NO/2 NC, 10A F.L.C, 10A Contact Rating, 24V ac
- RS Stock No.:
- 122-0807
- Mfr. Part No.:
- CWCA0-22-00D02
- Brand:
- WEG
Subtotal (1 unit)*
£24.92
(exc. VAT)
£29.90
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 25 September 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £24.92 |
*price indicative
- RS Stock No.:
- 122-0807
- Mfr. Part No.:
- CWCA0-22-00D02
- Brand:
- WEG
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | WEG | |
| Product Type | Overload Relay | |
| FLC Motor Rating | 10A | |
| Relay Contact Current | 10A | |
| Mount Type | DIN Rail | |
| Series | CWCA0 | |
| Terminal Type | Screw | |
| Normal State Configuration | 2 NO/2 NC | |
| IP Rating | IP20 | |
| Minimum Operating Temperature | -25°C | |
| Number of Auxiliary Contacts | 4 | |
| Width | 45mm | |
| Maximum Operating Temperature | 55°C | |
| Length | 58mm | |
| Contact Voltage | 690V ac | |
| Depth | 52mm | |
| Standards/Approvals | UL, IEC 60947-5-1, IEC 60947-4-1, CSA/IEC 60529 | |
| Control Voltage | 24V ac | |
| Select all | ||
|---|---|---|
Brand WEG | ||
Product Type Overload Relay | ||
FLC Motor Rating 10A | ||
Relay Contact Current 10A | ||
Mount Type DIN Rail | ||
Series CWCA0 | ||
Terminal Type Screw | ||
Normal State Configuration 2 NO/2 NC | ||
IP Rating IP20 | ||
Minimum Operating Temperature -25°C | ||
Number of Auxiliary Contacts 4 | ||
Width 45mm | ||
Maximum Operating Temperature 55°C | ||
Length 58mm | ||
Contact Voltage 690V ac | ||
Depth 52mm | ||
Standards/Approvals UL, IEC 60947-5-1, IEC 60947-4-1, CSA/IEC 60529 | ||
Control Voltage 24V ac | ||
RoHS Status: Exempt
- COO (Country of Origin):
- BR
CWC Series
Professional range of WEG contactors from the CWC Series designed for switching of electric motors. The contactors are modular and compact but at the same time robust and highly reliable. Built and tested according to IEC/EN60947 and DIN VDE 0660. Direct mounting capabilities. The controllers include contactors and reversing contactors.
AC/DC Operated
Screw Terminals
DIN Rail or Panel Mount
Compact space saving design
Built in auxiliary contacts
