WEG, CWC LINE Overload Relay 4 NO, 10A Contact Rating, 1000 kW, 230V ac 4
- RS Stock No.:
- 122-0801
- Mfr. Part No.:
- CWCA0-40-00D24
- Brand:
- WEG
Subtotal (1 unit)*
£24.92
(exc. VAT)
£29.90
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- 3 unit(s) shipping from 08 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £24.92 |
*price indicative
- RS Stock No.:
- 122-0801
- Mfr. Part No.:
- CWCA0-40-00D24
- Brand:
- WEG
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | WEG | |
| Product Type | Overload Relay | |
| Relay Contact Current | 10A | |
| Mount Type | DIN Rail | |
| Series | CWC LINE | |
| Pole and Throw Configuration | 4 | |
| Power Rating | 1000kW | |
| Normal State Configuration | 4 NO | |
| Terminal Type | Screw | |
| IP Rating | IP20 | |
| Minimum Operating Temperature | -25°C | |
| Width | 45mm | |
| Number of Auxiliary Contacts | 4 | |
| Contact Voltage | 690V ac | |
| Length | 58mm | |
| Maximum Operating Temperature | 55°C | |
| Standards/Approvals | IEC 60947-4-1, IEC 60947-2, IEC 60947-1, IEC 60034-30-1, EU Regulation 640/2009, Directive 2009/125/EC | |
| Depth | 52mm | |
| Supply Voltage | 1000, 50V | |
| Control Voltage | 230V ac | |
| Select all | ||
|---|---|---|
Brand WEG | ||
Product Type Overload Relay | ||
Relay Contact Current 10A | ||
Mount Type DIN Rail | ||
Series CWC LINE | ||
Pole and Throw Configuration 4 | ||
Power Rating 1000kW | ||
Normal State Configuration 4 NO | ||
Terminal Type Screw | ||
IP Rating IP20 | ||
Minimum Operating Temperature -25°C | ||
Width 45mm | ||
Number of Auxiliary Contacts 4 | ||
Contact Voltage 690V ac | ||
Length 58mm | ||
Maximum Operating Temperature 55°C | ||
Standards/Approvals IEC 60947-4-1, IEC 60947-2, IEC 60947-1, IEC 60034-30-1, EU Regulation 640/2009, Directive 2009/125/EC | ||
Depth 52mm | ||
Supply Voltage 1000, 50V | ||
Control Voltage 230V ac | ||
RoHS Status: Exempt
- COO (Country of Origin):
- BR
CWC Series
Professional range of WEG contactors from the CWC Series designed for switching of electric motors. The contactors are modular and compact but at the same time robust and highly reliable. Built and tested according to IEC/EN60947 and DIN VDE 0660. Direct mounting capabilities. The controllers include contactors and reversing contactors.
AC/DC Operated
Screw Terminals
DIN Rail or Panel Mount
Compact space saving design
Built in auxiliary contacts
