Radiall NEX10 Series, Plug Cable Mount BNC Connector, 50Ω, Plug-In Termination, Straight Body
- RS Stock No.:
- 171-9710
- Mfr. Part No.:
- R180052017W
- Brand:
- Radiall
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 171-9710
- Mfr. Part No.:
- R180052017W
- Brand:
- Radiall
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Radiall | |
| Gender | Male | |
| Coaxial Connector Type | BNC Connector | |
| Mounting Type | Cable Mount | |
| Impedance | 50Ω | |
| Termination Method | Plug-In | |
| Body Orientation | Straight | |
| Cable Type | RG402 | |
| Operating Frequency | 0 to 20GHz | |
| Minimum Operating Temperature | -55°C | |
| Body Plating | BBR | |
| Maximum Operating Temperature | +125°C | |
| Series | NEX10 | |
| Contact Material | Beryllium Copper, Brass | |
| Contact Plating | Silver | |
Select all | ||
|---|---|---|
Brand Radiall | ||
Gender Male | ||
Coaxial Connector Type BNC Connector | ||
Mounting Type Cable Mount | ||
Impedance 50Ω | ||
Termination Method Plug-In | ||
Body Orientation Straight | ||
Cable Type RG402 | ||
Operating Frequency 0 to 20GHz | ||
Minimum Operating Temperature -55°C | ||
Body Plating BBR | ||
Maximum Operating Temperature +125°C | ||
Series NEX10 | ||
Contact Material Beryllium Copper, Brass | ||
Contact Plating Silver | ||
- COO (Country of Origin):
- CN
Radiall’s NEX10™ series is a miniature and lightweight RF coaxial connector with excellent intermodulation performance for outdoor telecom applications up to 20 GHz. Radiall has partnered with two leading RF connector manufacturers to develop a new compact extremely robust Low PIM connector: NEX10™. With exceptional performance up to 20 GHz in order to meet the performance needs of customers, NEX10™ also features a compact design which is 50% smaller than 4.3-10.
Robust design for outdoor usage
Low PIM, independent of applied torque
Multiple coupling mechanism of push-pull and torque
RF shielding
Optimized for ” superflexible corrugated and smaller flexible cables
12.7mm minimum flange height
Contact areas protected from damage
Low PIM, independent of applied torque
Multiple coupling mechanism of push-pull and torque
RF shielding
Optimized for ” superflexible corrugated and smaller flexible cables
12.7mm minimum flange height
Contact areas protected from damage
