Radiall NEX10 Series, Jack Flange Mount BNC Connector, 50Ω, Solder Termination, Straight Body
- RS Stock No.:
- 171-8327
- Mfr. Part No.:
- R180252007W
- Brand:
- Radiall
- RS Stock No.:
- 171-8327
- Mfr. Part No.:
- R180252007W
- Brand:
- Radiall
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Radiall | |
| Coaxial Connector Type | BNC Connector | |
| Gender | Female | |
| Mounting Type | Flange Mount | |
| Impedance | 50Ω | |
| Termination Method | Solder | |
| Body Orientation | Straight | |
| Cable Type | RG402 | |
| Bulkhead | Yes | |
| Operating Frequency | 0 to 20GHz | |
| Minimum Operating Temperature | -55°C | |
| Body Plating | BBR | |
| Maximum Operating Temperature | +125°C | |
| Series | NEX10 | |
| Contact Material | Beryllium Copper | |
| Contact Plating | Silver | |
Select all | ||
|---|---|---|
Brand Radiall | ||
Coaxial Connector Type BNC Connector | ||
Gender Female | ||
Mounting Type Flange Mount | ||
Impedance 50Ω | ||
Termination Method Solder | ||
Body Orientation Straight | ||
Cable Type RG402 | ||
Bulkhead Yes | ||
Operating Frequency 0 to 20GHz | ||
Minimum Operating Temperature -55°C | ||
Body Plating BBR | ||
Maximum Operating Temperature +125°C | ||
Series NEX10 | ||
Contact Material Beryllium Copper | ||
Contact Plating Silver | ||
- COO (Country of Origin):
- CN
Radiall’s NEX10™ series is a miniature and lightweight RF coaxial connector with excellent intermodulation performance for outdoor telecom applications up to 20 GHz. Radiall has partnered with two leading RF connector manufacturers to develop a new compact extremely robust Low PIM connector: NEX10™. With exceptional performance up to 20 GHz in order to meet the performance needs of customers, NEX10™ also features a compact design which is 50% smaller than 4.3-10.
Robust design for outdoor usage
Low PIM, independent of applied torque
Multiple coupling mechanism of push-pull and torque
RF shielding
Optimized for ” superflexible corrugated and smaller flexible cables
12.7mm minimum flange height
Contact areas protected from damage
Low PIM, independent of applied torque
Multiple coupling mechanism of push-pull and torque
RF shielding
Optimized for ” superflexible corrugated and smaller flexible cables
12.7mm minimum flange height
Contact areas protected from damage
