RS PRO 75 Ω Coaxial Cable Screened, 100 m, 18 AWG White
- RS Stock No.:
- 520-3030
- Brand:
- RS PRO
Subtotal (1 reel of 100 metres)*
£207.03
(exc. VAT)
£248.44
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 2 unit(s) ready to ship
- Plus 3 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s) | Per Reel | Per Metre* |
|---|---|---|
| 1 + | £207.03 | £2.07 |
*price indicative
- RS Stock No.:
- 520-3030
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Product Type | Coaxial Cable | |
| Screened/Unscreened | Screened | |
| American Wire Gauge | 18AWG | |
| Characteristic Impedance | 75Ω | |
| Cable Length | 100m | |
| Jacket Colour | White | |
| Standards/Approvals | Euroclass Eca | |
| Jacket Material | Polyvinyl Chloride | |
| Select all | ||
|---|---|---|
Brand RS PRO | ||
Product Type Coaxial Cable | ||
Screened/Unscreened Screened | ||
American Wire Gauge 18AWG | ||
Characteristic Impedance 75Ω | ||
Cable Length 100m | ||
Jacket Colour White | ||
Standards/Approvals Euroclass Eca | ||
Jacket Material Polyvinyl Chloride | ||
- COO (Country of Origin):
- NL
RS PRO White Unterminated to Unterminated CT81 Coaxial Cable, 75 Ω, 7 mm OD, 100 m
Need to transmit cable or satellite TV over a long cable run? This CT81 coaxial cable from RS PRO is designed with the ideal electrical parameters for receiving digital TV via satellite or terrestrial transmissions. Cables of this kind are also used to transmit video and control cameras in CCTV systems.
The unit's copper strands offer excellent conductivity to transmit a clear signal and maintain image and audio quality. The cable is supplied unterminated so you can fit the conductors you need for your application.
The cable meets Euroclass ECA standards as a safe and effective copper network cable. Its polyvinyl chloride (PVC) sheath will help stop the spread in the event of a fire.
Features and Benefits
• Attenuation of 0.8 dB/10 m at 100 MHz
• Coaxial cable shape
• Capacitance of 55 pF/m
• Characteristic impedance of 75 Ω
• CT81 coaxial type
• Copper conductor material
• Solid conductor strand type
• Connector A is an unterminated connector type
• Connector B is an unterminated connector type
• L connector type
• PE (polyethylene) insulation material
• Length of 100 m
• One strand
• Outer diameter of 7 mm
• Reel length of 100 m
• White sheath colour
• Polyvinyl chloride (PVC) sheath material
• Strand size of 1 mm
• Euroclass Eca standards met
• Unterminated
