Female Connector Insert 3 Way for use with Mini Buccaneer Connector

  • RS Stock No. 531-598
  • Mfr. Part No. 12735/3/1
  • Brand Bulgin
Technical Reference
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): TN
Product Details

Plug & Socket Inserts

3 and 8-way inserts (accepting solder contacts, see for example, stock no 531-627 (pin contact) and 531-633 or 842-0051 (socket contact)
50 or 75Ω BNC
IP68 rated
Suitable for use with panel shells, see for example, 531-526 or cable shells, see for example, 531-510

//media.rs-online.com/t_line/LF531510-01.gif

Mini Buccaneer

Specifications
Attribute Value
Gender Female
Insert Type Carrier
Number of Contacts 3
For Use With Mini Buccaneer Connector
Maximum Operating Temperature +70°C
Minimum Operating Temperature -20°C
181 In stock - FREE next working day delivery available
Price Each
Was £0.63
£ 0.57
(exc. VAT)
£ 0.68
(inc. VAT)
Units
Per unit
1 +
£0.57
