Vishay, 47Ω 300W Thick Film Chassis Mount Resistor LPSA300H47R0JB ± 5%
- RS Stock No.:
- 212-1302
- Mfr. Part No.:
- LPSA300H47R0JB
- Brand:
- Vishay
Bulk discount available
Subtotal (1 unit)*
£53.22
(exc. VAT)
£63.86
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- Plus 55 unit(s) shipping from 27 October 2025
- Plus 999,999,944 unit(s) shipping from 12 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 1 | £53.22 |
| 2 - 4 | £52.16 |
| 5 - 9 | £45.25 |
| 10 - 24 | £42.57 |
| 25 + | £39.91 |
*price indicative
- RS Stock No.:
- 212-1302
- Mfr. Part No.:
- LPSA300H47R0JB
- Brand:
- Vishay
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Vishay | |
| Resistance | 47Ω | |
| Power Rating | 300W | |
| Series | LPS 300 | |
| Package/Case | Box | |
| Tolerance | ± 5% | |
| Technology | Thick Film | |
| Termination Style | Screw | |
| Minimum Operating Temperature | -55°C | |
| Maximum Operating Temperature | +120°C | |
| Minimum Temperature Coefficient | ±150ppm/°C | |
| Maximum Temperature Coefficient | ±500ppm/°C | |
| Dimensions | 60 x 57 x 25.2mm | |
| Overall Height | 25.2mm | |
| Overall Length | 60mm | |
Select all | ||
|---|---|---|
Brand Vishay | ||
Resistance 47Ω | ||
Power Rating 300W | ||
Series LPS 300 | ||
Package/Case Box | ||
Tolerance ± 5% | ||
Technology Thick Film | ||
Termination Style Screw | ||
Minimum Operating Temperature -55°C | ||
Maximum Operating Temperature +120°C | ||
Minimum Temperature Coefficient ±150ppm/°C | ||
Maximum Temperature Coefficient ±500ppm/°C | ||
Dimensions 60 x 57 x 25.2mm | ||
Overall Height 25.2mm | ||
Overall Length 60mm | ||
- COO (Country of Origin):
- CZ
The Vishay Power Resistor for Mounting onto a Heatsink Thick Film Technology Compliant with requirement #26 of NF-EN45545-2. High power 300 W at 85 °C bottom case temperature. Wide resistance range: 0.3 O to 900 kO E24 series
Non inductive
Easy mounting
Low thermal radiation of the case
Easy mounting
Low thermal radiation of the case
