MPN

RS PRO, 12 Ω 50 W Wirewound Chassis Mount Resistor ±5 %

RS Stock No.:: 185-2369
Brand:: RS PRO

RS PRO, 12 Ω 50 W Wirewound Chassis Mount Resistor ±5 %

Get a bulk buy discount

Add 5 more to save 16%

View bulk pricing options

Subtotal (1 unit)*

£7.04

(exc. VAT)

£8.45

(inc. VAT)

FREE delivery for orders over £60.00

In Stock

Plus 37 unit(s) shipping from 16 November 2026
Plus 13 unit(s) shipping from 16 November 2026
Plus 60 unit(s) shipping from 17 March 2027

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit	Saving
1 - 4	£7.04	-
5 - 9	£5.91	16%
10 - 19	£5.11	27%
20 +	£4.02	42%

*price indicative

RS Stock No.:: 185-2369
Brand:: RS PRO

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	RS PRO
	Product Type	Chassis Mount Resistor
	Resistance	12Ω
	Power Rating	50W
	Series	RS PRO
	Package/Case	Aluminium
	Tolerance	±5 %
	Technology	Wirewound
	Automotive Standard	No
	Termination Style	Wire Lead
	Minimum Operating Temperature	-25°C
	Overall Length	50mm
	Maximum Operating Temperature	250°C
	Standards/Approvals	RoHS
	Overall Width	75mm
	Overall Height	5.7mm

	Select all
	Brand RS PRO
	Product Type Chassis Mount Resistor
	Resistance 12Ω
	Power Rating 50W
	Series RS PRO
	Package/Case Aluminium
	Tolerance ±5 %
	Technology Wirewound
	Automotive Standard No
	Termination Style Wire Lead
	Minimum Operating Temperature -25°C
	Overall Length 50mm
	Maximum Operating Temperature 250°C
	Standards/Approvals RoHS
	Overall Width 75mm
	Overall Height 5.7mm

COO (Country of Origin):: IN

RS PRO Panel Mount Resistor

The RS PRO RSLPR50 series aluminium housed panel mount resistor has a resistance of 12ohm and power rating value of 50W. Its dimensions are 50mm x 75mm x 5.7mm (L x W x H). This low profile resistor is suitable for multiple industries and applications.

Features and Benefits

• Operating temperature ranging between -25°C and 250°C

• Tolerance: ±5%

• Dielectric strength: 2500VAC-rms for 1 minute

• Minimum insulation resistance: Greater than 100Mohm

Applications

• Electrical vehicles

• Power supplies

• Control devices

• Robotics

Certifications

• ANSI/ESD S20.20:2014

• BS EN 61340-5-1:2007
