Eaton 80A Ceramic Cartridge Fuse, 30 x 57mm
- RS Stock No.:
- 182-1831
- Mfr. Part No.:
- 80LR85
- Brand:
- Eaton
Bulk discount available
Subtotal (1 unit)*
£9.93
(exc. VAT)
£11.92
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 3 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 - 4 | £9.93 |
5 - 9 | £9.43 |
10 + | £8.84 |
*price indicative
- RS Stock No.:
- 182-1831
- Mfr. Part No.:
- 80LR85
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Eaton | |
Current Rating | 80A | |
Fuse Size | 30 x 57mm | |
Voltage Rating | 415V ac | |
Body Material | Ceramic | |
Application Category | gG | |
Fuse Standard | BS88-3 | |
Select all | ||
---|---|---|
Brand Eaton | ||
Current Rating 80A | ||
Fuse Size 30 x 57mm | ||
Voltage Rating 415V ac | ||
Body Material Ceramic | ||
Application Category gG | ||
Fuse Standard BS88-3 | ||
- COO (Country of Origin):
- IN
Eaton Cartridge Fuse, 80A Current Rating, 415V AC Voltage - 80LR85
This cartridge fuse is an essential component designed for low-voltage applications. This fuse measures 30 x 57 mm and is rated for a current capacity of 80A with a voltage rating of 415V AC. Built from durable ceramic material, this IEC 60269 fuse is suitable for a variety of industrial settings, ensuring reliable performance and safety.
Features & Benefits
• High current rating of 80A enhances operational efficiency
• Compact dimensions of 30 x 57 mm fit standard installations
• Ceramic construction offers superior resistance to harsh conditions
• Complies with IEC 60269 standards for increased safety
• Class gG fuse ensures effective overload protection
• Compact dimensions of 30 x 57 mm fit standard installations
• Ceramic construction offers superior resistance to harsh conditions
• Complies with IEC 60269 standards for increased safety
• Class gG fuse ensures effective overload protection
Applications
• Used with industrial machinery to prevent overloads
• Suitable for electrical panels in automation systems
• Compatible with various circuit protection requirements
• Ideal for requiring compliance with British standards
• Suitable for electrical panels in automation systems
• Compatible with various circuit protection requirements
• Ideal for requiring compliance with British standards
What is the significance of the ceramic material in this fuse?
The ceramic material provides high thermal resistance and mechanical strength, which helps to protect the internal components of the fuse from damage during operational stress and increases safety under overload conditions.
How does the voltage rating affect this fuse's performance?
A voltage rating of 415V ensures that the fuse can handle a range of electrical systems without risk of failure, allowing for reliable operation in high-voltage scenarios common in industrial applications.
What are the advantages of using a gG fuse in industrial settings?
A gG fuse is designed to protect against overload and short-circuit conditions, making it ideal for safeguarding motors and transformers in industrial environments, thus reducing the risk of equipment failure.
How does the breaking capacity of 33 kA benefit users?
The high breaking capacity allows the fuse to safely interrupt excessive fault currents, preventing damage to connected equipment and improving the overall safety of the electrical system.
Can this fuse be easily integrated into existing systems?
Yes, its standard size of 30 x 57 mm makes it compatible with many existing fuse holders and panels, facilitating effortless replacement and integration into current electrical setups.
Note
Eaton formerly known as Bussmann
