- RS Stock No.:
- 263-7971
- Mfr. Part No.:
- 74LVCH16543APAG
- Brand:
- Renesas Electronics
306 In stock - FREE next working day delivery available
Price Each (In a Tube of 34)
£1.555
(exc. VAT)
£1.866
(inc. VAT)
Units | Per unit | Per Tube* |
34 - 68 | £1.555 | £52.87 |
102 - 238 | £1.387 | £47.158 |
272 - 476 | £1.35 | £45.90 |
510 - 986 | £1.316 | £44.744 |
1020 + | £1.283 | £43.622 |
*price indicative |
- RS Stock No.:
- 263-7971
- Mfr. Part No.:
- 74LVCH16543APAG
- Brand:
- Renesas Electronics
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- TW
Product Details
The Renesas Electronics 16-bit transceiver is built using advanced dual metal CMOS technology. These high-speed, low-power transceivers are ideal for synchronous communication between two buses. The direction and output enable controls operate these devices as either two independent 8-bit transceivers or one 16-bit transceiver. The direction control pin controls the direction of data flow. The output enable pin overrides the direction control and disables both ports. All inputs are designed with hysteresis for improved noise margin.
Supports hot insertion
Available in SSOP and TSSOP packages
Reduced system switching noise
Available in SSOP and TSSOP packages
Reduced system switching noise
Specifications
Attribute | Value |
---|---|
Logic Family | 74LVCH |
Logic Function | Transceiver |
Number of Elements per Chip | 8 |
