Aim-TTi Digital Bench Power Supply 120W, 2 Output 0 → 30V 0 → 2A With UKAS Calibration

  • RS Stock No. 125-0813
  • Mfr. Part No. EL302RD
  • Brand Aim-TTi
Technical Reference
Legislation and Compliance
RoHS Status: Exempt
COO (Country of Origin): GB
Product Details

EL-R & EX-R Series Single, Dual and Triple Output PSUs

EL-R Series - Precision dc bench power supplies - Linear Regulation

Single outputs 30V/1A, 18V/3.3A, 56V/1.1A,15V/5A, 30V/3A
Single, dual or triple outputs, 30V/2A
Independent digital voltage and current meters for each output with 4 digit resolution
Switchable local or remote sensing
Constant voltage or constant current operation
Variable 1.5 - 5.0V auxiliary output at 2A (EL302RT)
Compact design uses less bench space
Silent fan-free cooling
DC output switches, automatic mode indication

30W to 130W Linear, Single, Dual & Triple Output

EX-R Series - Precision dc bench power supplies - Mixed-mode Regulation

Single output 35V/5A
Independent digital voltage and current meters for each output with 4 digit resolution
Switchable local or remote sensing
Constant voltage or constant current operation
Compact design uses less bench space
Silent fan-free cooling
DC output switches, automatic mode indication

175W, Single Output

Approvals

EN 61010-1 (Safety) and EN61326 (EMC)

Supplied with

user manual and mains lead

Specifications
Attribute Value
Output Voltage 0 → 30V
Output Current 0 → 2A
Number of Outputs 2
Type Digital
Power Rating 120W
Supply Voltage 115 V ac, 230 V ac
Number of Displays 4
Output Connector Binding Post Terminal
Calibrated UKAS
Minimum Temperature +5°C
Maximum Temperature +40°C
48 In stock for delivery within 2 working days
Price Each
£ 383.00
(exc. VAT)
£ 459.60
(inc. VAT)
Units
Per unit
1 +
£383.00
Not available for guaranteed pre 9am/10am delivery
