OPTIBELT Vee Belt Pulley Cast Iron 315 mm Pitch, 1 Tooth
- RS Stock No.:
- 238-6679
- Mfr. Part No.:
- TB SPA 315/1
- Brand:
- OPTIBELT
Subtotal (1 unit)*
£62.68
(exc. VAT)
£75.22
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 10 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £62.68 |
*price indicative
- RS Stock No.:
- 238-6679
- Mfr. Part No.:
- TB SPA 315/1
- Brand:
- OPTIBELT
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | OPTIBELT | |
| Number of Teeth | 1 | |
| Product Type | Vee Belt Pulley | |
| Pitch | 315mm | |
| Bore Size | 48 mm | |
| Material | Cast Iron | |
| Standards/Approvals | No | |
| Select all | ||
|---|---|---|
Brand OPTIBELT | ||
Number of Teeth 1 | ||
Product Type Vee Belt Pulley | ||
Pitch 315mm | ||
Bore Size 48 mm | ||
Material Cast Iron | ||
Standards/Approvals No | ||
The Optibelt KS V-grooved pulley for taper bushings profile SPA 13 TB SPA 315/100ZA and is balanced in one plane. Balancing is carried out minus the key on a smooth mandrel. Machines where the rotors are balanced with an adjusting spring inserted in the shaft end must be ordered as “Balanced with finished bore without key on a smooth mandrel without inserted spring".
Datum diameter is 315 mm
Number of grooves are 1
Cast iron pulley
