SKF 1 Hole Cylindrical, TUJ 40 TF 40 mm ID
- RS Stock No.:
- 464-838
- Mfr. Part No.:
- TUJ 40 TF
- Brand:
- SKF
Subtotal (1 unit)*
£90.11
(exc. VAT)
£108.13
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 16 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £90.11 |
*price indicative
- RS Stock No.:
- 464-838
- Mfr. Part No.:
- TUJ 40 TF
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Product Type | Bearing Unit | |
| Inside Diameter | 40mm | |
| Number of Mount Holes | 1 | |
| Locking Type | Screw | |
| Material | Cast Iron | |
| Length | 145mm | |
| Width | 49mm | |
| Depth | 115mm | |
| Standards/Approvals | RoHS | |
| Bore Type | Cylindrical | |
| Series | TUJ 40 TF | |
| Limiting Speed | 4800rpm | |
| Static Load Rating | 19kN | |
| Dynamic Load Rating | 30.7kN | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Product Type Bearing Unit | ||
Inside Diameter 40mm | ||
Number of Mount Holes 1 | ||
Locking Type Screw | ||
Material Cast Iron | ||
Length 145mm | ||
Width 49mm | ||
Depth 115mm | ||
Standards/Approvals RoHS | ||
Bore Type Cylindrical | ||
Series TUJ 40 TF | ||
Limiting Speed 4800rpm | ||
Static Load Rating 19kN | ||
Dynamic Load Rating 30.7kN | ||
- COO (Country of Origin):
- IT
The SKF Take-up ball bearing units, consisting of an insert bearing based on a sealed deep groove ball bearing mounted in a grey cast iron housing. Typically mounted in take-up frames, the unit has an inner ring extended on both sides and is locked by tightening a (set) screw on the inner ring, which makes it easy to mount.
Designed for an alternating rotation
Quick and easy to mount onto the shaft
Accommodate static initial misalignment
Long service life
Reduced noise and vibration levels
