Hirschmann Test & Measurement Green Female Banana Socket, 2mm Connector, Solder Termination, 6A, 60V dc, Nickel, Tin
- RS Stock No.:
- 190-2638
- Mfr. Part No.:
- 930308104
- Brand:
- Hirschmann Test & Measurement
Subtotal (1 pack of 100 units)*
£101.90
(exc. VAT)
£122.30
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 19 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 100 + | £1.019 | £101.90 |
*price indicative
- RS Stock No.:
- 190-2638
- Mfr. Part No.:
- 930308104
- Brand:
- Hirschmann Test & Measurement
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Hirschmann Test & Measurement | |
| Colour | Green | |
| Gender | Female | |
| Termination Method | Solder | |
| Voltage Rating | 60V dc | |
| Connector Size | 2mm | |
| Current Rating | 6A | |
| Contact Plating | Nickel, Tin | |
| Spring Contact | Yes | |
| Length | 21mm | |
| Contact Material | Beryllium Copper, Brass | |
| Type | Banana Socket | |
| Insulation Material | Polyamide | |
Select all | ||
|---|---|---|
Brand Hirschmann Test & Measurement | ||
Colour Green | ||
Gender Female | ||
Termination Method Solder | ||
Voltage Rating 60V dc | ||
Connector Size 2mm | ||
Current Rating 6A | ||
Contact Plating Nickel, Tin | ||
Spring Contact Yes | ||
Length 21mm | ||
Contact Material Beryllium Copper, Brass | ||
Type Banana Socket | ||
Insulation Material Polyamide | ||
Laboratory range 2 mm, tin-plated miniature socket
Ø 2 mm miniature socket, insulated, copper—beryllium contact spring, tin-plated with soldered connection.
Suitable for installation in unit chassis and control panels to a maximum wall thickness of 5 mm.
Dimensions: total depth: 21 mm; max. front panel thickness: 6 mm.
Suitable for installation in unit chassis and control panels to a maximum wall thickness of 5 mm.
Dimensions: total depth: 21 mm; max. front panel thickness: 6 mm.
