RS PRO Carbon Steel Full Bore, 2 Way, Ball Valve, BSPP 1/2in
- RS Stock No.:
- 764-4212
- Brand:
- RS PRO
47 In stock - FREE next working day delivery available
Added
Price Each
£50.72
(exc. VAT)
£60.86
(inc. VAT)
| Units | Per unit |
| 1 - 4 | £50.72 |
| 5 - 9 | £49.65 |
| 10 + | £48.04 |
- RS Stock No.:
- 764-4212
- Brand:
- RS PRO
Technical Reference
Legislation and Compliance
RoHS Status: Not Applicable
- COO (Country of Origin):
- CN
Product Details
Screwed End Ball Valve BSPP F-F 2013NM - 3 Piece
RS screwed end ball valves for the control of flow. Available in a variety of sizes.
Investment casting
Blow-out proof stem
Locking device
ISO 5211 Mounting pad
TA-Luft approved (option)
Length conform to DIN 3202/4-M3-2013SM3 (option)
Thread type: ASME B1.20.1 (NPT) DIN2999 and BS21 ISO7/1 and EN10226
Blow-out proof stem
Locking device
ISO 5211 Mounting pad
TA-Luft approved (option)
Length conform to DIN 3202/4-M3-2013SM3 (option)
Thread type: ASME B1.20.1 (NPT) DIN2999 and BS21 ISO7/1 and EN10226
Ball Valve, 3 Piece – Steel and Stainless Steel
3-piece design allows in-situ maintenance and servicing
Lockable Full Bore valves with thermally insulating lever sleeve
Incorporates ISO-5211 mounting flange for suitable actuator
Blow Out Proof Stem with Adjustable Stem packing
Seal, Thrust Washer, Stem Pack Material - P.T.F.E
Seat Material - P.T.F.E (15% Reinforced Glassfibre)
Lockable Full Bore valves with thermally insulating lever sleeve
Incorporates ISO-5211 mounting flange for suitable actuator
Blow Out Proof Stem with Adjustable Stem packing
Seal, Thrust Washer, Stem Pack Material - P.T.F.E
Seat Material - P.T.F.E (15% Reinforced Glassfibre)
Specifications
Attribute | Value |
|---|---|
| Type | Full Bore, 2 Way |
| Ball Material | Stainless Steel |
| Attachment Type | Threaded |
| Thread Standard | BSPP |
| Thread Size | 1/2in |
| Body Material | Carbon Steel |
| Safe for Use With | Gas, Oil, Water |
| Handle Type | Lever |
| Handle Material | Stainless Steel |
| Maximum Working Pressure psi | 1000psi |
| Maximum Working Pressure bar | 68bar |
| Handle Colour | Blue |
