FAG 30/5-B-2RSR-TVH-HLC Double Row Angular Contact Ball Bearing- Both Sides Sealed 5mm I.D, 14mm O.D
- RS Stock No.:
- 190-8349
- Mfr. Part No.:
- 30/5-B-2RSR-TVH-HLC
- Brand:
- FAG
Bulk discount available
Subtotal (1 unit)*
£33.37
(exc. VAT)
£40.04
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 76 unit(s) ready to ship
- Plus 20 unit(s) shipping from 13 October 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 - 4 | £33.37 |
5 - 9 | £32.04 |
10 - 24 | £31.36 |
25 + | £30.70 |
*price indicative
- RS Stock No.:
- 190-8349
- Mfr. Part No.:
- 30/5-B-2RSR-TVH-HLC
- Brand:
- FAG
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | FAG | |
Inside Diameter | 5mm | |
Outside Diameter | 14mm | |
Race Width | 7mm | |
Ball Bearing Type | Double Row Angular Contact Ball Bearing | |
Sealing Arrangement | Both Sides Sealed | |
Bearing Clearance | CN | |
Material | Steel | |
Ball Material | Steel | |
Cage Material | Steel | |
Number of Rows | 2 | |
Static Load Rating | 940N | |
Dynamic Load Rating | 1.78kN | |
Bore Type | Parallel | |
Bearing Series | 0 Extra Light | |
Partial Bearing Code | 30/5-B-2RSR | |
Race Type | Plain | |
Select all | ||
---|---|---|
Brand FAG | ||
Inside Diameter 5mm | ||
Outside Diameter 14mm | ||
Race Width 7mm | ||
Ball Bearing Type Double Row Angular Contact Ball Bearing | ||
Sealing Arrangement Both Sides Sealed | ||
Bearing Clearance CN | ||
Material Steel | ||
Ball Material Steel | ||
Cage Material Steel | ||
Number of Rows 2 | ||
Static Load Rating 940N | ||
Dynamic Load Rating 1.78kN | ||
Bore Type Parallel | ||
Bearing Series 0 Extra Light | ||
Partial Bearing Code 30/5-B-2RSR | ||
Race Type Plain | ||
Schaeffler 0 Extra Light Series Ball Bearing, 5mm Inside Diameter, 14mm Outside Diameter - 30/5-B-2RSR-TVH-HLC
This ball bearing is designed for precision and efficiency in various applications. With an inside diameter of 5mm and an outside diameter of 14mm, this double row angular contact ball bearing is manufactured to meet high-performance standards. Its design features sealing on both sides to prevent contamination and ensure longevity.
Features & Benefits
• Features a double row design for increased load handling
• Constructed with steel for enhanced durability and strength
• Both sides sealed to protect against debris and moisture
• Supports dynamic loads up to 1.78kN for robust performance
• Designed for axial loads in both directions for versatility
• Compatible with standard installation requirements for easy setup
• Constructed with steel for enhanced durability and strength
• Both sides sealed to protect against debris and moisture
• Supports dynamic loads up to 1.78kN for robust performance
• Designed for axial loads in both directions for versatility
• Compatible with standard installation requirements for easy setup
Applications
• Used in systems requiring reliable motion control
• Suitable for electric motor assemblies where load balance is crucial
• Ideal for precision instruments that demand high accuracy
• Applied in systems needing durable, sealed support
• Utilised in robotics for enhanced mobility and reliability
• Suitable for electric motor assemblies where load balance is crucial
• Ideal for precision instruments that demand high accuracy
• Applied in systems needing durable, sealed support
• Utilised in robotics for enhanced mobility and reliability
What is the typical operating temperature range for this bearing?
The bearing operates efficiently within a temperature range from -30°C to 120°C, accommodating various environmental conditions.
How does the sealing arrangement contribute to the bearing's longevity?
The dual sealing arrangement prevents contamination from dirt and moisture, significantly extending the lifespan and maintaining performance.
What load ratings should be considered during installation?
The basic dynamic load rating for radial loads is 1.78kN, while the static load rating is 940N, essential for ensuring proper functionality.
What factors influence the performance of this type of bearing?
Performance can be influenced by operating temperature, lubrication method, and installation precision, all of which are essential for optimal use.
