Amphenol FCI 1.27mm Pitch Backplane Connector, Female, Right Angle, 1 Row, 22 Way 10034814

  • RS Stock No. 860-0071
  • Mfr. Part No. 10034814-001LF
  • Brand Amphenol FCI
Technical Reference
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): MY
Product Details

FCI SATA Connectors

FCI offers a wide range of SATA plug and receptacle connector configurations with vertical or right angle options.

Most backplane connectors also feature stamped retention clips that provide additional mechanical strength for robust PCB attachment and different termination type namely, through-hole solder, press-fit or surface-mount.

For implementation of the high-speed serial-ATA storage interface
22 position SATA connectors meet requirements of Serial ATA specification
Provides 7 contacts for signal port and 15 contacts for power
Designed to support hot-plugging and blind-mating of HDDs
Connector retainers provide additional mechanical strength after soldering

PCB Mounted

Specifications
Attribute Value
Gender Female
Number of Contacts 22
Number of Rows 1
Body Orientation Right Angle
Housing Material Thermoplastic
Pitch 1.27mm
Contact Material Copper Alloy
Contact Plating Gold over Nickel
Current Rating 1.5A
Voltage Rating 500 V ac
Termination Method Solder
Maximum Operating Temperature +260°C
Series Number 10034814
Available to back order for despatch 07/04/2020
Price Each (In a Pack of 330)
£ 3.94
(exc. VAT)
£ 4.73
(inc. VAT)
Units
Per unit
Per Pack*
330 +
£3.94
£1,300.20
*price indicative
