RS PRO 4.70mm Pitch Rack and Panel Connector Backplane Connector, Female, Straight, 8 Row, 8 Way
- RS Stock No.:
- 434-496
- Brand:
- RS PRO
Bulk discount available
Subtotal (1 unit)*
£33.52
(exc. VAT)
£40.22
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 28 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 - 9 | £33.52 |
10 + | £30.84 |
*price indicative
- RS Stock No.:
- 434-496
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | RS PRO | |
Backplane Connector Type | Rack and Panel Connector | |
Gender | Female | |
Number of Contacts | 8 | |
Number of Rows | 8 | |
Body Orientation | Straight | |
Pitch | 4.70mm | |
Contact Material | Diallyl-Phthalate | |
Mounting Type | Panel Mount | |
Contact Plating | Gold | |
Current Rating | 5A | |
Voltage Rating | 800V ac/dc | |
Termination Method | Solder | |
Minimum Operating Temperature | -55°C | |
Maximum Operating Temperature | 125°C | |
Select all | ||
---|---|---|
Brand RS PRO | ||
Backplane Connector Type Rack and Panel Connector | ||
Gender Female | ||
Number of Contacts 8 | ||
Number of Rows 8 | ||
Body Orientation Straight | ||
Pitch 4.70mm | ||
Contact Material Diallyl-Phthalate | ||
Mounting Type Panel Mount | ||
Contact Plating Gold | ||
Current Rating 5A | ||
Voltage Rating 800V ac/dc | ||
Termination Method Solder | ||
Minimum Operating Temperature -55°C | ||
Maximum Operating Temperature 125°C | ||
- COO (Country of Origin):
- GB
RS PRO Rack and Panel Connector, 5 A Current Rating
This heavy-duty rectangular rack and panel connector system is designed for rugged conditions, offering reliable line-to-line or panel connections. With a low insertion force, the plug and socket self-align, making it ideal for inaccessible applications.
Features and Benefits
Rugged construction ensures durability in harsh environments
180° polarised for secure connections
Floating bushes assist alignment, enhancing ease of use
Excellent current carrying characteristics for efficient performance
Available in four sizes with 8, 16, 24, and 32 contacts for versatile applications
5 A current rating supports robust electrical connections
Working voltage of 800 V DC or AC peak for high-voltage applications
UL-94 V-0 rated flame-retardant for safety compliance
180° polarised for secure connections
Floating bushes assist alignment, enhancing ease of use
Excellent current carrying characteristics for efficient performance
Available in four sizes with 8, 16, 24, and 32 contacts for versatile applications
5 A current rating supports robust electrical connections
Working voltage of 800 V DC or AC peak for high-voltage applications
UL-94 V-0 rated flame-retardant for safety compliance
Applications
Industrial automation
Telecommunications
Aerospace
Defence systems
Telecommunications
Aerospace
Defence systems
Additional Information
Contact Plating: Gold Plated
Termination Method: Solder
Operating Temperature Range: -55 °C to 125 °C
Housing Material: Diallyl-Phthalate
Contact Material: Copper Alloy
Mounting Type: Panel Mount
Termination Method: Solder
Operating Temperature Range: -55 °C to 125 °C
Housing Material: Diallyl-Phthalate
Contact Material: Copper Alloy
Mounting Type: Panel Mount
