ebm-papst 500 F Series Axial Fan, 12 V dc, DC Operation, 20m³/h, 800mW, 67mA Max, 50 x 50 x 15mm
- RS Stock No.:
- 299-1497
- Mfr. Part No.:
- 512F
- Brand:
- ebm-papst
1416 In stock - FREE next working day delivery available
17 available from Europe for delivery within 1 working day(s).
Added
Price Each
£26.42
(exc. VAT)
£31.70
(inc. VAT)
| Units | Per unit |
| 1 - 4 | £26.42 |
| 5 - 9 | £24.46 |
| 10 - 24 | £23.46 |
| 25 - 49 | £22.56 |
| 50 + | £21.69 |
- RS Stock No.:
- 299-1497
- Mfr. Part No.:
- 512F
- Brand:
- ebm-papst
Legislation and Compliance
- COO (Country of Origin):
- HU
Product Details
Miniature and Slimline Fans
ebm papst offer a wide range of DC axial fans that can be integrated into a range of concept devices. ebm papst DC fans have electronically commutated drives which protect against reverse polarity. DC fans have the added feature of a long life expectancy due to the increased efficiency of the brushless drives.
• Ideal for low profile applications
• Can be mounted for blowing or extracting
• Can be mounted for blowing or extracting
Approvals
UL; CSA
Specifications
Attribute | Value |
|---|---|
| Supply Voltage | 12 V dc |
| AC or DC Operation | DC |
| Height | 50mm |
| Power Consumption | 800mW |
| Width | 50mm |
| Depth | 15mm |
| Maximum Current | 67mA |
| Air Flow | 20m³/h |
| Dimensions | 50 x 50 x 15mm |
| Noise Level | 30dB |
| Fan Speed | 5000rpm |
| Bearing Type | Sleeve |
