RS PRO Axial Fan, 230 V ac, AC Operation, 0.4m³/min, 6W, 35mA Max, 92 x 92 x 25mm
- RS Stock No.:
- 255-7333
- Brand:
- RS PRO
Bulk discount available
Subtotal (1 unit)*
£38.82
(exc. VAT)
£46.58
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 36 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 - 9 | £38.82 |
10 - 99 | £37.27 |
100 + | £31.05 |
*price indicative
- RS Stock No.:
- 255-7333
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | RS PRO | |
Supply Voltage | 230 V ac | |
AC or DC Operation | AC | |
Height | 92mm | |
Width | 92mm | |
Power Consumption | 6W | |
Maximum Current | 35mA | |
Depth | 25mm | |
Termination Type | Wire | |
Air Flow | 0.4m³/min | |
Dimensions | 92 x 92 x 25mm | |
Fan Speed | 1800rpm | |
Bearing Type | Ball | |
Select all | ||
---|---|---|
Brand RS PRO | ||
Supply Voltage 230 V ac | ||
AC or DC Operation AC | ||
Height 92mm | ||
Width 92mm | ||
Power Consumption 6W | ||
Maximum Current 35mA | ||
Depth 25mm | ||
Termination Type Wire | ||
Air Flow 0.4m³/min | ||
Dimensions 92 x 92 x 25mm | ||
Fan Speed 1800rpm | ||
Bearing Type Ball | ||
- COO (Country of Origin):
- CN
RS PRO AC Operation 230 V/ac 6 W Axial Fan 92 x 92 x 25 mm
From RS PRO we offer you an AC Motor Operation black plastic Axial Fan with 6 W input power and wire connection. The Axial fan is extremely efficient and hard wearing as is uses ball bearings to ensure a smooth operation plus is cost effective with an operating life of at least 50,000 hours at 40°C. Excellent air flow and speed, easy mounting, versatile cooling solution and quick wire connection are just a small number of the benefits supplied by the RS PRO Axial Fan.
Features & Benefits
- AC Axial fan
- Made from black plastic
- Square shaped
- Ball bearing, 50,000 hours at 40°C
- Operating temperature range -10°C to +70°C
- Input power 6 W
- 50 Hz
- Fan speed 1800 RPM
- Rated current of 0.035 A
- Mounting hole diameter 4.4 mm
- CE, UKCA, RoHS Certified
Applications
- Various cooling applications
- Network communications
- Server racks
- Electrical cabinets and enclosures
- Information technology equipment
What are Axial fans?
Axial fans are used across all industries where the cooling of components or machinery is important. Fans work by drawing air in an axial direction across a surface to cool it or to push hot air away to cool it. This is essential in everyday items such as a desktop PC, where the axial fan would cool down the processor to ensure the computer would continue to operate smoothly. Overheating concerns apply to most electronic or engineering applications, and so axial fans are needed.
Why RS PRO?
RS PRO is our own brand range and brings you a wide range of high-quality, great value products offering you more choice. Trusted by engineers all over the world, every part of every RS PRO product has been rigorously tested against demanding industry standards
theyre only given the RS PRO seal of approval if were confident of their exceptional quality, which means you can be confident too.
Approvals
CE, UKCA, RoHS
