Sanyo Denki Axial Fan, 24 V dc, DC Operation, 3.12W, 130mA Max, 92 x 92 x 25mm
- RS Stock No.:
- 236-8466
- Mfr. Part No.:
- 9RA0924P4G001
- Brand:
- Sanyo Denki
Bulk discount available
Subtotal (1 unit)*
£25.42
(exc. VAT)
£30.50
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 18 unit(s) ready to ship
- Plus 4 unit(s) ready to ship from another location
- Plus 35 unit(s) shipping from 25 November 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 - 4 | £25.42 |
5 - 9 | £23.90 |
10 - 24 | £22.37 |
25 - 49 | £21.35 |
50 + | £19.31 |
*price indicative
- RS Stock No.:
- 236-8466
- Mfr. Part No.:
- 9RA0924P4G001
- Brand:
- Sanyo Denki
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Sanyo Denki | |
Supply Voltage | 24 V dc | |
AC or DC Operation | DC | |
Height | 92mm | |
Power Consumption | 3.12W | |
Width | 92mm | |
Depth | 25mm | |
Maximum Current | 130mA | |
Dimensions | 92 x 92 x 25mm | |
Select all | ||
---|---|---|
Brand Sanyo Denki | ||
Supply Voltage 24 V dc | ||
AC or DC Operation DC | ||
Height 92mm | ||
Power Consumption 3.12W | ||
Width 92mm | ||
Depth 25mm | ||
Maximum Current 130mA | ||
Dimensions 92 x 92 x 25mm | ||
- COO (Country of Origin):
- PH
The Sanyo Denki DC fan have ribs and pulse sensors with PWM control function is most sought after product. Compared to other models noise level has been halved and power consumption has been reduced by 26%. Moreover, the models with PWM control, which enables the control of fan speed, provide further optimized noise level and efficiency. This fan lasts 1.5 times longer than the current model, (1) and is capable of continuous operation for 60, 000 hours, improving the maintainability. The product line up is available in a wide variety in voltage, cooling performance, noise level, and PWM control. This allows users to choose the most suitable one for their applications. Operating voltage range for this product is 21.6 to 26.4 V. Frame material is plastic. Operating temperature -20 to +70 ˚C. Dimensions of this fan is 92 x 92 x 25 mm.
Low noise and energy saving
Long life
Rich line up
Eco product
Long life
Rich line up
Eco product
