Sanyo Denki 109P Series Axial Fan, 24 V dc, DC Operation, 18cfm, 6W, 250mA Max, 40 x 40 x 28mm

View all Axial Fans
Bulk discount available

Subtotal (1 unit)*

£16.46

(exc. VAT)

£19.75

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 69 unit(s) ready to ship
  • Plus 145 unit(s) ready to ship from another location
  • Plus 20 unit(s) shipping from 28 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 - 4£16.46
5 - 9£15.47
10 - 24£14.48
25 - 49£13.82
50 +£12.50

*price indicative

RS Stock No.:
191-9245
Distrelec Article No.:
301-54-349
Mfr. Part No.:
109P0424R3013
Brand:
Sanyo Denki
Find similar products by selecting one or more attributes.
Select all

Brand

Sanyo Denki

Supply Voltage

24 V dc

Height

40mm

AC or DC Operation

DC

Width

40mm

Power Consumption

6W

Depth

28mm

Maximum Current

250mA

Termination Type

Lead Wire

Air Flow

18cfm

Dimensions

40 x 40 x 28mm

Noise Level

47dB(A)

Sensor Type

Pulse

Direction of Curve

Forward

Bearing Type

Ball

COO (Country of Origin):
PH
Our DC cooling fans have features such as high airflow, high reliability, and low noise. They can be used in a wide-ranging applications including servers and ICT equipment.

The San Ace DC Fans feature high airflow, high static pressure, low power consumption and low vibration. In the development phase, we thoroughly reviewed impeller shape, motor characteristics, operating airflow, and expected life to achieve target performance. We realized excellent cooling performance by leveraging our technology accumulated over a long period of time.

The Sanyo Denki DC fan of series San Ace 109P has a plastic frame having flammability of UL 94V-0. Its impeller is also made up of plastic. It has -30°C to +70°C storage temperature.

Locked rotor burnout protection
Reverse polarity protection
