Sanyo Denki 109P Series Axial Fan, 24 V dc, DC Operation, 6.4cfm, 1.92W, 80mA Max, 40 x 40 x 15mm
- RS Stock No.:
- 191-9240
- Distrelec Article No.:
- 301-40-213
- Mfr. Part No.:
- 109P0424H701
- Brand:
- Sanyo Denki
Bulk discount available
Subtotal (1 unit)*
£14.52
(exc. VAT)
£17.42
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 100 unit(s) ready to ship
- Plus 63 unit(s) ready to ship from another location
- Plus 70 unit(s) shipping from 30 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 - 4 | £14.52 |
5 - 9 | £13.67 |
10 - 24 | £12.78 |
25 - 49 | £12.22 |
50 + | £11.05 |
*price indicative
- RS Stock No.:
- 191-9240
- Distrelec Article No.:
- 301-40-213
- Mfr. Part No.:
- 109P0424H701
- Brand:
- Sanyo Denki
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Sanyo Denki | |
Supply Voltage | 24 V dc | |
Height | 40mm | |
AC or DC Operation | DC | |
Power Consumption | 1.92W | |
Width | 40mm | |
Maximum Current | 80mA | |
Depth | 15mm | |
Dimensions | 40 x 40 x 15mm | |
Air Flow | 6.4cfm | |
Termination Type | Lead Wire | |
Noise Level | 28dB(A) | |
Direction of Curve | Forward | |
Sensor Type | Pulse | |
Bearing Type | Ball | |
Select all | ||
---|---|---|
Brand Sanyo Denki | ||
Supply Voltage 24 V dc | ||
Height 40mm | ||
AC or DC Operation DC | ||
Power Consumption 1.92W | ||
Width 40mm | ||
Maximum Current 80mA | ||
Depth 15mm | ||
Dimensions 40 x 40 x 15mm | ||
Air Flow 6.4cfm | ||
Termination Type Lead Wire | ||
Noise Level 28dB(A) | ||
Direction of Curve Forward | ||
Sensor Type Pulse | ||
Bearing Type Ball | ||
- COO (Country of Origin):
- PH
Our DC cooling fans have features such as high airflow, high reliability, and low noise. They can be used in a wide-ranging applications including servers and ICT equipment.
The San Ace DC Fans feature high airflow, high static pressure, low power consumption and low vibration. In the development phase, we thoroughly reviewed impeller shape, motor characteristics, operating airflow, and expected life to achieve target performance. We realized excellent cooling performance by leveraging our technology accumulated over a long period of time.
The Sanyo Denki DC fan of series San Ace 109P has a plastic frame having flammability of UL 94V-0. Its impeller is also made up of plastic. It has -30°C to +70°C storage temperature.
Locked rotor burnout protection
Reverse polarity protection
Reverse polarity protection
