Lovato Auxiliary Contact, 2 Contact, 1 NO/1 NC, BG, DIN Rail, 10 A, 690V, 11BGX1011
- RS Stock No.:
- 901-0854
- Mfr. Part No.:
- 11BGX1011
- Brand:
- Lovato
Subtotal (1 unit)*
£12.03
(exc. VAT)
£14.44
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 8 unit(s) shipping from 04 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £12.03 |
*price indicative
- RS Stock No.:
- 901-0854
- Mfr. Part No.:
- 11BGX1011
- Brand:
- Lovato
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Lovato | |
| Number of Contacts | 2 | |
| Product Type | Auxiliary Contact | |
| Normal State Configuration | 1 NO/1 NC | |
| Series | BG | |
| Mount Type | DIN Rail | |
| Contact Current | 10A | |
| Terminal Type | Screw | |
| Pole and Throw Configuration | DPST | |
| Contact Voltage | 690V | |
| Minimum Operating Temperature | -50°C | |
| Mechanical Durability | 20000000Operations | |
| Rated Insulation Voltage Ui | 690V | |
| Mounting Location | Side Mounting | |
| Operational Current Ie | 10A | |
| Maximum Operating Temperature | 70°C | |
| Standards/Approvals | CSA C22.2 n° 14, UL508, IEC/EN 60947-1, IEC/EN 60947-5-1 | |
| Select all | ||
|---|---|---|
Brand Lovato | ||
Number of Contacts 2 | ||
Product Type Auxiliary Contact | ||
Normal State Configuration 1 NO/1 NC | ||
Series BG | ||
Mount Type DIN Rail | ||
Contact Current 10A | ||
Terminal Type Screw | ||
Pole and Throw Configuration DPST | ||
Contact Voltage 690V | ||
Minimum Operating Temperature -50°C | ||
Mechanical Durability 20000000Operations | ||
Rated Insulation Voltage Ui 690V | ||
Mounting Location Side Mounting | ||
Operational Current Ie 10A | ||
Maximum Operating Temperature 70°C | ||
Standards/Approvals CSA C22.2 n° 14, UL508, IEC/EN 60947-1, IEC/EN 60947-5-1 | ||
RoHS Status: Not Applicable
BG Series Auxiliary Contacts
Range of auxiliary contacts with front centre mounting and screw terminals suitable for BG Series mini-contactors
