Bulgin, PX0101 Connector Housing Female Black Free Hanging 4 Way Crimp Termination PX0101P04BK
- RS Stock No.:
- 267-9877
- Mfr. Part No.:
- PX0101P04BK
- Brand:
- Bulgin
Bulk discount available
View bulk pricing optionsSubtotal (1 box of 900 units)*
£583.20
(exc. VAT)
£700.20
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 900 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Box* |
|---|---|---|
| 900 - 900 | £0.648 | £583.20 |
| 1800 - 1800 | £0.625 | £562.50 |
| 2700 - 2700 | £0.608 | £547.20 |
| 3600 - 3600 | £0.592 | £532.80 |
| 4500 + | £0.577 | £519.30 |
*price indicative
- RS Stock No.:
- 267-9877
- Mfr. Part No.:
- PX0101P04BK
- Brand:
- Bulgin
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Bulgin | |
| Product Type | Connector Housing | |
| Sub Type | Rectangular Connector | |
| Termination Type | Crimp | |
| Number of Contacts | 4 | |
| Current | 13A | |
| Gender | Female | |
| Number of Rows | 2 | |
| Mount Type | Free Hanging | |
| Series | PX0101 | |
| Colour | Black | |
| Cord Included | No | |
| IP Rating | IP68 | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 120°C | |
| Width | 20.2mm | |
| Height | 20mm | |
| Depth | 31.6mm | |
| Standards/Approvals | IP68, RoHS | |
| Housing Material | Polybutylene Terephthalate | |
| Contact Plating | Nickel Plated | |
| Contact Material | Copper Alloy | |
| Select all | ||
|---|---|---|
Brand Bulgin | ||
Product Type Connector Housing | ||
Sub Type Rectangular Connector | ||
Termination Type Crimp | ||
Number of Contacts 4 | ||
Current 13A | ||
Gender Female | ||
Number of Rows 2 | ||
Mount Type Free Hanging | ||
Series PX0101 | ||
Colour Black | ||
Cord Included No | ||
IP Rating IP68 | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 120°C | ||
Width 20.2mm | ||
Height 20mm | ||
Depth 31.6mm | ||
Standards/Approvals IP68, RoHS | ||
Housing Material Polybutylene Terephthalate | ||
Contact Plating Nickel Plated | ||
Contact Material Copper Alloy | ||
- COO (Country of Origin):
- CN
The Bulgin standard rectangular connector with 4 contact female connector, that comes with Y-type and welded flange with crimp terminal. That having shrink boot adapter, protective end cap.
Water and dustproof
Contact type plug
