Unavailable
RS will no longer stock this product.
- RS Stock No.:
- 775-5022
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Number of Cores | 2 | |
| Screened/Unscreened | Screened | |
| Insulation Material | PE | |
| Outer Diameter | 6.2mm | |
| Length | 100m | |
| Minimum Operating Temperature | -20°C | |
| Maximum Operating Temperature | +80°C | |
| Sheath Colour | Black | |
| American Wire Gauge | 25 AWG | |
| Screen Type | Braid | |
| Capacitance Core To Core | 59pF/m | |
| Number of Strands | 40 | |
| Core Strands | 40/0.08 mm | |
| Size of Strands | 0.08 mm | |
| Sheath Material | Polyvinyl Chloride PVC | |
| Cable Shape | Multicore | |
| Conductor Resistance | 92 Ω/km | |
| Conductor Strand Type | Solid | |
| Voltage Rating | 600 V | |
| Conductor Material | Bare Copper | |
| Select all | ||
|---|---|---|
Brand RS PRO | ||
Number of Cores 2 | ||
Screened/Unscreened Screened | ||
Insulation Material PE | ||
Outer Diameter 6.2mm | ||
Length 100m | ||
Minimum Operating Temperature -20°C | ||
Maximum Operating Temperature +80°C | ||
Sheath Colour Black | ||
American Wire Gauge 25 AWG | ||
Screen Type Braid | ||
Capacitance Core To Core 59pF/m | ||
Number of Strands 40 | ||
Core Strands 40/0.08 mm | ||
Size of Strands 0.08 mm | ||
Sheath Material Polyvinyl Chloride PVC | ||
Cable Shape Multicore | ||
Conductor Resistance 92 Ω/km | ||
Conductor Strand Type Solid | ||
Voltage Rating 600 V | ||
Conductor Material Bare Copper | ||
- COO (Country of Origin):
- CN
