S2Ceb-Groupe CaeS2CEB Series Audio & Control Cable, 0.14 mm² CSA, 7.4mm od, 10m, Black
- RS Stock No.:
- 372-9754
- Mfr. Part No.:
- MPAP2T5000
- Brand:
- S2Ceb-Groupe Cae
Image representative of range
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 372-9754
- Mfr. Part No.:
- MPAP2T5000
- Brand:
- S2Ceb-Groupe Cae
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | S2Ceb-Groupe Cae | |
| Audio Cable Type | Audio & Control Cable | |
| Cross Sectional Area | 0.14 mm² | |
| Insulation Material | PE | |
| Outer Diameter | 7.4mm | |
| Length | 10m | |
| Minimum Operating Temperature | -30°C | |
| Maximum Operating Temperature | +85°C | |
| Fire Behaviour | Flame Retardant | |
| Sheath Colour | Black | |
| American Wire Gauge | 24 AWG | |
| Cable Shape | Twisted Pair | |
| Standards Met | Euroclass Eca | |
| Core Strands | 18/0.1 mm | |
| Series | S2CEB | |
| Sheath Material | PVC | |
| Number of Strands | 18 | |
| Size of Strands | 0.1 mm | |
| Voltage Rating | 500 V | |
| Conductor Material | Bare Copper | |
Select all | ||
|---|---|---|
Brand S2Ceb-Groupe Cae | ||
Audio Cable Type Audio & Control Cable | ||
Cross Sectional Area 0.14 mm² | ||
Insulation Material PE | ||
Outer Diameter 7.4mm | ||
Length 10m | ||
Minimum Operating Temperature -30°C | ||
Maximum Operating Temperature +85°C | ||
Fire Behaviour Flame Retardant | ||
Sheath Colour Black | ||
American Wire Gauge 24 AWG | ||
Cable Shape Twisted Pair | ||
Standards Met Euroclass Eca | ||
Core Strands 18/0.1 mm | ||
Series S2CEB | ||
Sheath Material PVC | ||
Number of Strands 18 | ||
Size of Strands 0.1 mm | ||
Voltage Rating 500 V | ||
Conductor Material Bare Copper | ||
- COO (Country of Origin):
- IT
Shielded audio multi-pair cables for MPAP mobile applications
Extra-flexible multi-pair cables mainly designed for use in mobile applications or by service providers.
These cables consist of pairs shielded via taping and individually insulated.
Each twisted pair is numbered (black marking on grey sheath).
These cables are resistant to the various mechanical stresses that may be imposed on them.
These cables consist of pairs shielded via taping and individually insulated.
Each twisted pair is numbered (black marking on grey sheath).
These cables are resistant to the various mechanical stresses that may be imposed on them.
