Vishay 100μF Aluminium Electrolytic Capacitor 63V dc, Axial, Through Hole - MAL211890514E3
- RS Stock No.:
- 850-5922
- Mfr. Part No.:
- MAL211890514E3
- Brand:
- Vishay
Bulk discount available
Subtotal (1 unit)*
£2.90
(exc. VAT)
£3.48
(inc. VAT)
FREE delivery for orders over £50.00
Last RS stock
- 322 left, ready to ship
- Plus 124 left, ready to ship from another location
- Final 732 unit(s) shipping from 09 October 2025
Units | Per unit |
---|---|
1 - 9 | £2.90 |
10 - 24 | £2.32 |
25 - 49 | £2.03 |
50 - 99 | £1.74 |
100 + | £1.60 |
*price indicative
- RS Stock No.:
- 850-5922
- Mfr. Part No.:
- MAL211890514E3
- Brand:
- Vishay
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Vishay | |
Capacitance | 100µF | |
Voltage | 63V dc | |
Mounting Type | Axial, Through Hole | |
Technology | Aluminium Electrolytic | |
Dimensions | 10 (Dia.) x 25mm | |
Length | 25mm | |
Minimum Operating Temperature | -40°C | |
Diameter | 10mm | |
Maximum Operating Temperature | +125°C | |
Lifetime | 500h | |
Tolerance | ±20% | |
Ripple Current | 243mA | |
Equivalent Series Resistance | 1.1Ω | |
Series | 118 AHT | |
Leakage Current | 42 μA | |
Select all | ||
---|---|---|
Brand Vishay | ||
Capacitance 100µF | ||
Voltage 63V dc | ||
Mounting Type Axial, Through Hole | ||
Technology Aluminium Electrolytic | ||
Dimensions 10 (Dia.) x 25mm | ||
Length 25mm | ||
Minimum Operating Temperature -40°C | ||
Diameter 10mm | ||
Maximum Operating Temperature +125°C | ||
Lifetime 500h | ||
Tolerance ±20% | ||
Ripple Current 243mA | ||
Equivalent Series Resistance 1.1Ω | ||
Series 118 AHT | ||
Leakage Current 42 μA | ||
Vishay 118 AHT Series
Vishay 118 AHT series aluminium electrolytic capacitors are a high temperature cylindrical insulated case with a long life design. The 118 AHT series is suitable for a wide range of applications including automotive, industrial, telecommunication, smoothing, filtering, coupling, decoupling and timing.
Polarized axial leads
Charge and discharge proof
Extra-long useful life
Vibration and shock resistant
Charge and discharge proof
Extra-long useful life
Vibration and shock resistant
Axial 125°C
