Nichicon 330μF Aluminium Electrolytic Capacitor 450V dc, Snap-In - LGL2W331MELA45
- RS Stock No.:
- 846-6896P
- Mfr. Part No.:
- LGL2W331MELA45
- Brand:
- Nichicon
Bulk discount available
Subtotal 10 units (supplied in a box)*
£74.60
(exc. VAT)
£89.50
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 198 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 10 - 24 | £7.46 |
| 25 - 99 | £7.11 |
| 100 - 249 | £5.98 |
| 250 + | £5.76 |
*price indicative
- RS Stock No.:
- 846-6896P
- Mfr. Part No.:
- LGL2W331MELA45
- Brand:
- Nichicon
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Nichicon | |
| Capacitance | 330µF | |
| Voltage | 450V dc | |
| Mounting Type | Snap-In | |
| Technology | Aluminium Electrolytic | |
| Dimensions | 25 (Dia.) x 45mm | |
| Height | 45mm | |
| Minimum Operating Temperature | -25°C | |
| Diameter | 25mm | |
| Maximum Operating Temperature | +105°C | |
| Lead Pitch | 10mm | |
| Lifetime | 2000h | |
| Leakage Current | 1.15 mA | |
| Series | GL | |
| Tolerance | ±20% | |
| Ripple Current | 1.12A | |
Select all | ||
|---|---|---|
Brand Nichicon | ||
Capacitance 330µF | ||
Voltage 450V dc | ||
Mounting Type Snap-In | ||
Technology Aluminium Electrolytic | ||
Dimensions 25 (Dia.) x 45mm | ||
Height 45mm | ||
Minimum Operating Temperature -25°C | ||
Diameter 25mm | ||
Maximum Operating Temperature +105°C | ||
Lead Pitch 10mm | ||
Lifetime 2000h | ||
Leakage Current 1.15 mA | ||
Series GL | ||
Tolerance ±20% | ||
Ripple Current 1.12A | ||
- COO (Country of Origin):
- JP
GL Series Ultra Small
Snap-in Terminal Type Al Electrolytic Capacitors
105°C Ultra-Smaller-Sized thus suited for equipment down sizing
105°C Ultra-Smaller-Sized thus suited for equipment down sizing
